Two white rectangular powerline adapters with gigabit ethernet ports and status LEDs

D-Link

D-Link DHP-701AV AV2000 MIMO Gigabit powerline networking starter kit

SKU CH-BJ8C-JY9RK MPN DHP-701AV

A two-adapter kit extends a wired network over household electrical wiring at up to 2.0 Gbps with Gigabit Ethernet ports and MIMO technology

  • StandardsIEEE 802.3 IEEE 802.3u HomePlug AV HomePlug AV2 IEEE 1901
  • PortsEthernet port
  • LEDsPower, PowerLine, LAN (from right to left)
  • Powerline SpeedsUp to 2.0Gbps
  • Connection TypeRJ45
  • Connection Speeds10/100/1000M
  • Extend network reach using existing electrical wiring
  • Up to 2.0 Gbps bandwidth with HomePlug AV2 MIMO
  • Gigabit Ethernet ports deliver 1000 Mbps wired speed
  • Plug-and-play setup creates a network in seconds
  • Backward compatible with HomePlug AV1.1 devices

Extend network via electrical wiring

The D-Link DHP-701AV starter kit uses HomePlug AV2 MIMO technology to deliver up to 2000 Mbps powerline speeds over existing electrical circuits. Two DHP-700AV adapters and two Ethernet cables are included for immediate plug-and-play deployment. Gigabit Ethernet ports provide wired 10/100/1000M connections at each outlet. Backward compatibility with HomePlug AV1.1 preserves older powerline devices on the same network.

Fits a build with free wall outlets

Each adapter requires a spare mains socket operating on 100 to 240 VAC at 50 to 60 Hz; power strips or surge protectors can reduce throughput. The compact 1.34 x 3.89 x 2.86 inch form factor leaves adjacent sockets accessible. One-touch push-button security pairs the units without software, freeing the user from router configuration. LEDs for Power, PowerLine and LAN give instant link-status visibility.

Handles multi-room streaming and gaming

The AV2 2000 MIMO link comfortably serves 4K video, large file transfers and low-latency gaming across rooms on the same electrical phase. Throughput drops when adapters span different circuit breakers or encounter heavy line noise from appliances. Operating temperature range of 32 to 104 °F and 10 to 90 % non-condensing humidity suit typical indoor environments. Storage tolerance extends from -4 to 149 °F for seasonal conditions.

Erősségek

  • Extend network reach using existing electrical wiring
  • Up to 2.0 Gbps bandwidth with HomePlug AV2 MIMO
  • Gigabit Ethernet ports deliver 1000 Mbps wired speed
  • Plug-and-play setup creates a network in seconds
  • Backward compatible with HomePlug AV1.1 devices

Műszaki adatok

BrandD-Link
ModelDHP-701AV
StandardsIEEE 802.3
IEEE 802.3u
HomePlug AV
HomePlug AV2
IEEE 1901
PortsEthernet port
LEDsPower, PowerLine, LAN (from right to left)
Powerline SpeedsUp to 2.0Gbps
Connection TypeRJ45
Connection Speeds10/100/1000M
Kit TypeDouble
Power Supply100~240VAC, 50~60Hz
System RequirementWindows 7, Windows 8, or Mac OS X (10.7 or higher)
TemperatureOperating: 32 to 104 degree F
Storage: -4 to 149 degree F
HumidityOperating: 10% to 90% non-condensing
Storage: 5% to 95% non-condensing
FeaturesConvenience - Get a high-speed network using your existing electrical wiring
PowerLine AV2 Technology - Speeds of up to 2000Mpbs
Ports - Gigabit Ethernet Ports for Gigabit speeds
SetUp - Plug-and-Play installation
Power Savings - Power saving mode reduces power consumption up to 85%
Security - 128-bit AES Link Encryption with key management for secure power line communications
Dimensions1.34" x 3.89" x 2.86"
Weight0.40 lbs.
Package Contents2 x PowerLine AV2 2000 Gigabit Adapters (DHP-700AV)
Warranty documents
2 x Ethernet Cables
Quick Installation Guide
Szállítási súly0.59 kg
Csomagméret216 × 140 × 99 mm

Kérdések a termékről

What throughput limit appears first when the DHP-701AV adapters run at full load for hours?

The Gigabit Ethernet ports cap sustained traffic at 1000 Mbps even though the powerline link is rated for up to 2000 Mbps.

How much heat do the DHP-701AV units produce when they stay powered all day?

They are rated for continuous operation between 32 and 104 °F with 10 % to 90 % non-condensing humidity.

Which wired devices can I connect directly to the DHP-701AV kit without extra hardware?

Any device with an RJ45 port that negotiates 10, 100 or 1000 Mbps — PCs, consoles, smart TVs, NAS units — plugs straight into the two included Ethernet cables.
