Green Micro ATX motherboard with silver LGA 1151 socket, two black DDR4 slots, single PCIe x16 slot, six SATA ports and rear I/O shield

GIGABYTE

GIGABYTE B150M-D3V rev.1.0 Intel motherboard

SKU CH-CSXE-BY5YY

Micro-ATX board for LGA 1151 CPUs with Intel B150 chipset, two DDR4 slots supporting 32 GB, one PCIe x16 slot, six SATA ports, one M.2 slot, Realtek ALC887 audio and gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU TypeSupports LGA1151 slot 7th/6th generation processors: Intel C
  • ChipsetIntel B150
  • Maximum Memory Supported32GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID1XM.2 interface, 6xSATA III interface
  • Supports 6th and 7th generation Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB capacity
  • Micro-ATX form factor measuring 24.4 by 17.4 cm
  • Realtek ALC887 audio with 7.1 channel support
  • Six SATA III ports plus one M.2 interface

B150 Micro-ATX board for LGA 1151 builds

This GIGABYTE B150M-D3V revision 1.0 motherboard fits the Micro-ATX form factor and uses the Intel B150 chipset. It accepts 6th and 7th generation Intel Core i7, i5, i3, Pentium and Celeron processors in the LGA 1151 socket. Two DDR4 DIMM slots support up to 32 GB of system memory. The board measures 24.4 by 17.4 cm.

Suits budget LGA 1151 upgrades.

Builders refreshing an older LGA 1151 system or assembling a basic office PC will find the single PCI Express x16 slot and six SATA III ports adequate. Buyers who need multiple graphics cards, additional high-speed expansion slots or integrated Wi-Fi should look at larger ATX boards with richer chipset implementations.

One full-length PCI Express x16 slot

The only x16 slot on this board runs at x16 electrical speed and is the primary connection for a discrete graphics card. No second x16 or x8 slot is present, so multi-GPU configurations are not supported. Confirm that your build requires only a single graphics card before purchasing.

Privalumai

  • Supports 6th and 7th generation Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB capacity
  • Micro-ATX form factor measuring 24.4 by 17.4 cm
  • Realtek ALC887 audio with 7.1 channel support
  • Six SATA III ports plus one M.2 interface

Specifikacijos

BrandGIGABYTE
SeriesGIGABYTE B150M-D3V(rev.1.0)
ModelGIGABYTE B150M-D3V(rev.1.0)
CPU Socket TypeLGA 1151
CPU TypeSupports LGA1151 slot 7th/6th generation processors: Intel Core ™ i7 processor/Intel Core ™ i5 processor/Intel Core ™ i3 processor/Intel Pentium processor/Intel Celeron processor
* Support 7th generation Intel Core ™ processor Please update the latest version of BIOS. ®
2. L3 cache depends on CPU
ChipsetIntel B150
Maximum Memory Supported32GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications (PCIEX16)
To maximize the performance of the graphics card, it is necessary to install it in the PCIEX16 slot when installing a graphics card.
2 PCI Express x1 slots
All PCI Express slots support PCI Express 3.0.
3. 1 PCI slot
SATA RAID1XM.2 interface, 6xSATA III interface
Audio Chipset1. Built-in Realtek ALC887 chip ®
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
To activate the 7.1 channel audio output, you must use the front panel audio output of the HD (High Definition, High Fax) audio module and select the multi-channel audio function through the audio software.
4. Support S/PDIF output
LAN ChipsetBuilt-in Realtek GbE network chip (10/100/1000 Mbit)
Onboard USBBuilt-in chipset:
1.6 USB 3.0/2 ports (4 on the rear panel, 2 to be connected from the USB socket in the main board via cable)
2.6 USB 2.0/1 ports (2 on the rear panel, 4 to be connected from the USB socket in the main board via cable)

Klausimai apie šią prekę

Which memory capacity should I pick for this B150M-D3V board?

The board has two DDR4 DIMM slots and supports a maximum of 32 GB, so install two 16 GB modules to reach the limit.

What does the 32 GB maximum mean once the board is in a real machine?

With both slots filled you can run 32 GB of DDR4, giving plenty of headroom for multitasking and typical desktop workloads.

What interface does the M.2 slot use and what speed does it cap at in practice?

The single M.2 interface connects through the B150 chipset and runs at SATA speeds, so any drive installed there will be limited to the SATA III throughput.
