PCIe network card with eight RJ45 ports and PoE+ support

LR-LINK

LR-LINK 8-Port Gigabit PoE+ Network Card 10/100/1000Mbps

SKU CH-VH96-RCWG6

Adds eight Gigabit PoE+ ports with up to 30W per port and hardware TCP/IP offload for Windows Server, Linux and VMware

  • StandardsIEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
  • Speed10/100/1000Mbps
  • Connectors8*RJ45
  • Temperature0°C ~ 55°C
  • Humidity5 % ~ 95 % (Non-condensing)
  • Class8 Port Gigabit PoE+

Class 8 Port Gigabit PoE+

  • Eight ports deliver gigabit speeds up to 1000 Mbps
  • PoE+ supplies up to 30 W per port for powered devices
  • Intel I350 dual-controller hardware offloads TCP/IP checksum and segmentation
  • Single PCIe x4 card works in x4, x8 or x16 slots
  • Supports Windows Server 2003, 2008, 2012, Windows 7, 8, Linux and VMware

Eight-Port PoE+ Adapter for Industrial Servers

This LR-LINK network card adds eight Gigabit RJ45 ports through a single PCI Express x4 slot, compatible with x8 and x16 channels. It is built on the Intel I350 chip solution and targets industrial vision inspection servers, high-speed mobile Ethernet gear, and general-purpose servers that need dense copper connectivity. Each port delivers up to 30 W of PoE+ power for cameras or access points.

Thermals Power and Noise in Normal Use

The card operates from 0 °C to 55 °C in 5 % to 95 % non-condensing humidity, meeting typical server-room conditions. Hardware acceleration offloads TCP, UDP and IP checksums plus TCP segmentation, reducing host CPU load during sustained throughput. An external 4-pin power connector supplies the PoE budget, keeping the slot power draw within standard limits.

Build Connectors and Daily Implications

Eight RJ45 jacks consolidate multiple network drops into one add-in card, preserving motherboard expansion slots for other tasks. The bracket fits a standard full-height PCIe opening and the 4-pin power lead reaches most server power supplies without adapters. Driver support covers Windows Server 2003, 2008, 2012, Windows 7, 8, Linux and VMware ESX for broad deployment flexibility.

Privalumai

  • Eight ports deliver gigabit speeds up to 1000 Mbps
  • PoE+ supplies up to 30 W per port for powered devices
  • Intel I350 dual-controller hardware offloads TCP/IP checksum and segmentation
  • Single PCIe x4 card works in x4, x8 or x16 slots
  • Supports Windows Server 2003, 2008, 2012, Windows 7, 8, Linux and VMware

Specifikacijos

BrandLR-LINK
StandardsIEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
Speed10/100/1000Mbps
Connectors8*RJ45
Temperature0°C ~ 55°C
Humidity5 % ~ 95 % (Non-condensing)
Class8 Port Gigabit PoE+

Kiti šio modelio variantai

Dar 1 toje pačioje serijoje

Ta pati šeima, bet skiriasi atmintis, aušintuvas ar dažnis — palyginkite prieš apsispręsdami.

Klausimai apie šią prekę

How do I install this PCIe x4 card and power the PoE+ ports correctly?

Insert the card into a PCIe x4, x8 or x16 slot, then connect the external 4-pin power connector so each of the eight RJ45 ports can deliver up to 30 W of PoE+ power.

What maintenance will the eight RJ45 ports and onboard Intel I350 controllers need over time?

Keep the ports free of dust, verify the 4-pin power connector stays seated, and apply driver or firmware updates from the OS vendor to maintain checksum offload and TCP segmentation performance.

At what temperature does the card hit its thermal limit during sustained 8-port PoE+ loads?

The operating range tops out at 55 °C; sustained full-power PoE+ on all eight ports will reach that limit first if chassis airflow is restricted.
