Black micro-ATX motherboard with silver heatsinks and pre-installed I/O shield

MSI

MSI MAG B660M BAZOOKA DDR4 Intel motherboard

SKU CH-V3SJ-MHC1P

Micro-ATX board for 12th and 13th Gen Intel CPUs with DDR4 memory, dual Gen4 M.2 slots, 2.5 Gbps LAN and extended VRM heatsinks

  • CPU Socket TypeLGA 1700 * Dedicated LGA1700 mounting bracket is required.
  • CPU TypeSupports 13th / 12th Gen Intel Core, Pentium Gold, Celeron P
  • ChipsetIntel B660
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardDDR4 4800+ (OC)
  • Supports 12th and 13th Gen Intel Core CPUs on LGA 1700 socket
  • Extended PWM heatsink keeps high-end processors running at full speed
  • Gen4 M.2 slots deliver up to 64 Gbps bandwidth for fast storage
  • 5 Gbps LAN with Realtek 8125BG gives low-latency wired networking
  • Four DDR4 slots support up to 128 GB at 4800+ MT/s dual-channel

Socket LGA 1700 DDR4 motherboard

The MSI MAG B660M BAZOOKA DDR4 uses the Intel B660 chipset to support 12th and 13th Gen Core, Pentium Gold and Celeron processors in a Micro ATX form factor. Four 288‑pin slots accept up to 128 GB of DDR4 4800 memory in dual‑channel mode. One PCIe 4.0 x16 slot, one PCIe 3.0 x16 slot and a PCIe 3.0 x1 slot handle graphics and add‑in cards.

Extended heatsink and M.2 thermal solution

An extended PWM heatsink covers the power delivery area to keep high‑end CPUs running at full speed without active cooling on the VRM. The M.2 Shield Frozr sits over both Gen4 x4 slots to draw heat away from installed SSDs and prevent throttling. A pre‑installed I/O shield adds EMI protection and simplifies the build process.

2.5 Gbps LAN and four SATA ports

The Realtek 8125BG controller provides a single 2.5 Gbps Ethernet port with LAN Manager software for traffic prioritisation. Four SATA 6 Gb/s connectors support traditional hard drives and SATA SSDs. Realtek ALC897 audio delivers 7.1‑channel output for speakers or headsets. A dedicated LGA 1700 mounting bracket is required for cooler installation.

Privalumai

  • Supports 12th and 13th Gen Intel Core CPUs on LGA 1700 socket
  • Extended PWM heatsink keeps high-end processors running at full speed
  • Gen4 M.2 slots deliver up to 64 Gbps bandwidth for fast storage
  • 5 Gbps LAN with Realtek 8125BG gives low-latency wired networking
  • Four DDR4 slots support up to 128 GB at 4800+ MT/s dual-channel

Specifikacijos

BrandMSI
ModelMAG B660M BAZOOKA DDR4
CPU Socket TypeLGA 1700
* Dedicated LGA1700 mounting bracket is required.
CPU TypeSupports 13th / 12th Gen Intel Core, Pentium Gold, Celeron Processors
ChipsetIntel B660
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 4800+ (OC)
Maximum Memory Supported128GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express 4.0 x16
PCI Express 3.0 x161 x PCI Express 3.0 x16
PCI Express x11 x PCI Express 3.0 x1
Serial ATA (SATA)4 x SATA 6Gb/s
M.22 x M.2 Gen4 x4 64 Gbps slots
Intel Optane ReadyYes
Audio ChipsetRealtek ALC897
Audio Channels7.1 Channels
LAN ChipsetRealtek 8125BG
Max LAN Speed2.5Gbps
Back I/O Ports1 x DisplayPort
1 x HDMI
1 x LAN (RJ45)
1 x PS/2 Keyboard/Mouse Combo
2 x USB 2.0/1.1
2 x USB 3.2 Gen 1
2 x USB 3.2 Gen 2
3 x Audio Jacks
Windows 11Supported
Form FactorMicro ATX
LED LightingRGB

Klausimai apie šią prekę

How do I install the LGA 1700 CPU and what step is commonly missed?

A dedicated LGA 1700 mounting bracket is required; many builders forget to fit it before seating the processor.

What maintenance will the M.2 thermal solution need later?

The M.2 Shield Frozr heatsink is passive; just clear dust from its fins during routine cleaning to keep SSD temperatures low.

What limit appears first when the 2.5 Gbps LAN runs at full load for a long time?

The Realtek 8125BG controller caps wired throughput at 2.5 Gbps, so sustained transfers cannot exceed that ceiling.
