APC Smart-UPS SMT2200 2200 VA 1920 W UPS
Provides 1920 W battery backup with ten NEMA outlets and a Smart-Slot interface
- International Version120V
- Input Voltage Range82 - 144V Adjustable range: 75 - 154V
- Input Frequency50/60 Hz +/- 3 Hz (auto sensing)
- Input ConnectionNEMA 5-20P
- VA Rating1920 VA
- Watts1920 Watts
Options SMT2200
- SMT2200
- SMT1000
- SMT1500NC
- SMT1500RM2U
- SMT3000
- SMT3000RM2U
- SMT3000RM2UNC
- SMTL750RM2UC
- SMTL1000RM2UC
- SMTL1000RM2UCNC
- SMTL1500RM3UC
- SMTL1500RM3UCNC
Skatīt vēl 1 konfigurācijas
- SMTL2200RM2UC
Pārsvītrotās versijas pastāv, taču šeit nav pieejamas.
- 1920 W output keeps critical servers running during outages
- 10 outlets including 5-20R and 5-15R connect mixed IT gear
- 530 J surge rating absorbs damaging transients
- SmartSlot interface enables remote monitoring and management
- 3-hour recharge restores full backup capacity quickly
Tower UPS for servers and networking gear
The APC Smart-UPS SMT2200 is a 1920 W tower UPS designed to keep rack-mounted servers, storage arrays and network switches running during utility outages or brownouts. Its 120 V input and output suit North American IT closets and small data rooms.
Replaces basic surge strips
A jump to this model is warranted when connected loads exceed the capacity of entry-level units or when runtime must survive extended power events. The 3-hour recharge cycle and user-replaceable RBC55 battery module let administrators restore full protection without replacing the entire chassis.
Ten outlets handle dense equipment racks
Eight NEMA 5-15R and two NEMA 5-20R receptacles support mixed plug types at up to 2200 VA. The 530 J surge rating absorbs transient spikes, while the SmartSlot interface accepts optional management cards for remote monitoring. Loads above 1920 W will overload the inverter.
Priekšrocības
- 1920 W output keeps critical servers running during outages
- 10 outlets including 5-20R and 5-15R connect mixed IT gear
- 530 J surge rating absorbs damaging transients
- SmartSlot interface enables remote monitoring and management
- 3-hour recharge restores full backup capacity quickly
Specifikācijas
| Brand | APC |
|---|---|
| Series | Smart-UPS |
| Model | SMT2200 |
| International Version | 120V |
| Input Voltage Range | 82 - 144V Adjustable range: 75 - 154V |
| Input Frequency | 50/60 Hz +/- 3 Hz (auto sensing) |
| Input Connection | NEMA 5-20P |
| VA Rating | 1920 VA |
| Watts | 1920 Watts |
| Output Voltage | 120V |
| Output Frequency | 50/60Hz +/- 3 Hz |
| Outlets | 10 |
| Outlet Type | (8) NEMA 5-15R (2) NEMA 5-20R |
| Battery Recharge Time | 3 hour(s) |
| Battery Replaceable | RBC55 |
| Alarms | Alarm when on battery : distinctive low battery alarm : configurable delays |
| Interface Port | Smart-Slot |
| Surge Energy Rating | 530 Joules |
| Features | Receptacles: 8 x NEMA 5-20R,2 x NEMA 5-15RLoad Capacity (VA): 2200 VALoad Capacity (Watt): 1980 WInput Voltage: 110 V ACOutput Voltage: 120 V ACMaximum Battery Recharge Time: 3 HourHeight: 17" (431.8 mm)Width: 7.7" (195.6 mm)Depth: 21.5" (546.1 mm)Form Factor: TowerWeight (Approximate): 50.80 kgPackage Contents: Smart-UPS SMT2200 2200VA Tower UPSCD with softwareDocumentation CDSmart UPS signalling RS-232 cableUSB cableGreen Compliant: YesGreen Compliance Certificate/Authority: RoHSLimited Warranty: 3 Year |
| Dimensions | 17.01" x 7.72" x 21.42" (H x W x D) |
| Weight | 112.00 lbs. |
| Package Contents | Smart-UPS SMT2200 2200VA Tower UPS CD with software Documentation CD Smart UPS signalling RS-232 cable USB cable |
| Sūtījuma svars | 57.02 kg |
| Sūtījuma izmēri | 795 × 686 × 381 mm |
Citas šī modeļa versijas
Vēl 5 šajā sērijā
Viena saime, taču atšķirīga atmiņa, dzesētājs vai frekvence — salīdziniet, pirms izlemjat.
APC
APC Smart-UPS SMT1500RM2U 1550VA 1000W 2U Rackmount UPS
- Input voltage range…
- 50/60 Hz +/- 3 Hz (…
585,99 $723,99 $−19%
0.00753259BTC
Krājumā
APC
APC SMTL750RM2UC 750VA 600W 120V 6x NEMA 5-15R 680J UPS
- 82 - 144V
- NEMA 5-15P
1 113,99 $
0.01431974BTC
Krājumā
Jautājumi par šo preci
How deep is the SMT2200 tower so I can check rack or shelf clearance?
The unit measures 21.5 inches (546.1 mm) deep, 7.7 inches (195.6 mm) wide and 17 inches (431.8 mm) high, weighing approximately 50.80 kg.
Which cable do I plug into the Smart-Slot for network management?
The Smart-Slot accepts an optional APC management card; the included USB and RS-232 signalling cables connect to the dedicated USB and serial ports, not the Smart-Slot.
When the battery eventually fails, which replacement cartridge do I order?
Order the RBC55 replacement battery cartridge; it is hot-swappable so the UPS stays online while you swap the pack.
