White PTZ dome camera, cylindrical body, ceiling mount bracket visible

Axis Communications

Axis Communications P5655-E 01682-004 PTZ network camera

SKU CH-6840-P7GDW MPN 01682-004

A cost-effective PTZ network camera delivering HDTV 1080p resolution with 32x optical zoom, Forensic WDR, Lightfinder 2.0, electronic image stabilization, IP66 and IK10 ratings.

  • Network CameraYes
  • TypePTZ Camera
  • ColorWhite
  • Mounting LocationYes
  • Networking ProtocolIPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPS, TLS, Q
  • ONVIFYes
  • HDTV 1080p clarity backed by 32x optical zoom
  • Forensic WDR and Lightfinder 2.0 handle extreme contrast and low light
  • Signed firmware plus secure boot protect the camera from tampering
  • Electronic image stabilization and focus recall keep footage steady
  • Zipstream with H.264 and H.265 cuts bandwidth and storage needs

Purpose-built surveillance

The Axis Communications P5655-E 01682-004 is a PTZ network camera delivering HDTV 1080p resolution with 32x optical zoom and 12x digital zoom for detailed coverage. It suits operators who need a single unit to monitor wide areas and zoom in on specific incidents without deploying multiple fixed cameras.

Installation and connectivity

The camera carries IP66, NEMA 4X and IK10 ratings for resistance to harsh weather and impact. It mounts on ceilings and accepts power via IEEE 802.3at PoE+ or 20–28 V DC and 20–24 V AC inputs. Networking uses IPv4, IPv6 and a full suite of protocols including HTTPS, TLS 1.2/1.3, ONVIF and Zipstream with H.264/H.265 support.

Upgrade path and fit

This model replaces older PTZ units that lack Forensic WDR, Lightfinder 2.0 or electronic image stabilisation for clearer footage in mixed lighting and vibration. It is not for buyers who need resolution beyond 1920x1080 or zoom beyond 384x total. The 256 preset positions and guard tour functions suit automated patrol workflows rather than manual-only operation.

Priekšrocības

  • HDTV 1080p clarity backed by 32x optical zoom
  • Forensic WDR and Lightfinder 2.0 handle extreme contrast and low light
  • Signed firmware plus secure boot protect the camera from tampering
  • Electronic image stabilization and focus recall keep footage steady
  • Zipstream with H.264 and H.265 cuts bandwidth and storage needs

Specifikācijas

BrandAXIS
ModelP5655-E
Part Number01682-004
Network CameraYes
TypePTZ Camera
ColorWhite
Mounting LocationYes
Networking ProtocolIPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPS, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, NTCIP, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
ONVIFYes
Pan/TiltYes
Pan/Tilt/ZoomPan: 360° endless, 0.1°- 350°/s
Tilt: 180°, 0.1°- 350°/s
Zoom: 32x optical, 12x digital, Total 384x zoom 256 preset positions, nadir flip, limited guard tour, control queue, on-screen directional indicator, set new pan 0°, focus window, focus recall
Sensor & DetectorCMOS
MAX Resolution1920x1080 HDTV 1080p to 320x180
Frame RateUp to 60/50 fps (60/50 Hz) in all resolutions
Lens TypeVarifocal, 4.3-137.6 mm, F1.4 - 4.0
Horizontal field of view: 58.3°- 2.4°
Vertical field of view: 35.5°- 1.4°
Including EIS, barrel and pincushion distortion correction
Autofocus and auto-iris
SecurityIEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AE (MACsec PSK/EAP-TLS), HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 Certificate PKI, host-based firewall
AudioAudio
Audio streaming: Two-way, full duplex
Audio encoding: 24bit LPCM, AAC-LC 8/16/32/44.1/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48 kHz
Configurable bit rate
Audio input/output: External microphone input or line input, line output (Requires Axis 10-pin Push-pull System Connector or Axis Multicable C I/O Audio Power 1 m/5 m, not included), automatic gain control
Power over EthernetYes
PowerAxis PoE+ midspan 1–port: 100–240 V AC, max 37 W
IEEE 802.3at, Type 2 Class 4
Camera consumption: typical 10.5 W, max 19 W
Multiconnector:
20–28 V DC, typical 10 W, max 18 W
20–24 V AC, typical 15.5 V A, max 26 V A
(PoE+ midspan or power supply not included)
DimensionHeight: 217 mm (8.54 in)
ø 188 mm (7.4 in)
Weight2.5 kg (5.5 lb)
Sūtījuma svars3.24 kg
Sūtījuma izmēri381 × 229 × 224 mm

Jautājumi par šo preci

What networking protocols does the AXIS P5655-E support, and which ones handle secure video streaming?

The camera supports IPv4, IPv6, HTTP, HTTPS, TLS v1.2/v1.3, RTSP, RTP, SRTP/RTSPS and ONVIF for secure video streaming and device management.

What are the physical dimensions and mounting requirements for the P5655-E?

The camera measures 217 mm tall with a 188 mm diameter, weighs approximately 2.4 kg and is designed for ceiling mounting with IP66, NEMA 4X and IK10 environmental ratings.

How is the AXIS P5655-E powered and what is the most common installation mistake?

It uses IEEE 802.3at PoE+ (Type 2 Class 4) requiring a 37 W midspan; the common mistake is using standard PoE (802.3af) which provides insufficient power for PTZ operation.
