Black PTZ camera body with integrated zoom lens, matte finish, wall-mount base visible

SMTAV

SMTAV NDI PTZ Camera 20x Optical 16x Digital Zoom Black

SKU CH-GW50-QV4BT

IP camera with 20x optical and 16x digital zoom, 1080p output, NDI and PoE support, plus HDMI and 3G-SDI connections

  • Bundled Camera Number1 Camera
  • Camera Type1
  • ColorBlack
  • Mounting Locationno
  • Wirelessno
  • Networking ProtocolNDI PTZ,VISCA over IP, VISCA, Pelco-D, Pelco-P, CGI, HTTP, O
  • 20× optical zoom brings distant detail close
  • 16× digital zoom extends reach further
  • H.265 encoding cuts bandwidth for 1080p streams
  • PoE power simplifies single-cable installation
  • ONVIF plus NDI and VISCA over IP ensure broad system compatibility

NDI PTZ Camera with 20x Optical Zoom

The SMTAV NDI PTZ Camera is a network-connected pan-tilt-zoom camera built for live streaming and video conferencing. It delivers 1080p resolution at up to 60 frames per second through HDMI, 3G-SDI and IP outputs simultaneously. The 1/2.7 inch CMOS sensor provides 2.07 effective megapixels with H.265 encoding for efficient bandwidth use.

Suitable for fixed installations needing remote

This camera suits operators who require VISCA over IP, ONVIF or serial control via RS-232 and RS-485 for integration into production workflows. Power over Ethernet simplifies cabling for permanent mounts. Buyers needing wireless connectivity or battery operation should look elsewhere, as the unit requires a wired network connection.

20x optical zoom lens with 150-metre SDI reach

The lens offers 20x optical zoom (f=4.42–88.5 mm, F1.8–F2) plus 16x digital zoom for framing flexibility. 3G-SDI output supports cable runs up to 150 metres at 1080p30, while HDMI and IP streams operate concurrently. Operating temperature ranges from -10 °C to 40 °C.

Priekšrocības

  • 20× optical zoom brings distant detail close
  • 16× digital zoom extends reach further
  • H.265 encoding cuts bandwidth for 1080p streams
  • PoE power simplifies single-cable installation
  • ONVIF plus NDI and VISCA over IP ensure broad system compatibility

Specifikācijas

BrandSMTAV
SeriesNDI PTZ Camera
ModelNDI PTZ Camera
Bundled Camera Number1 Camera
Camera Type1
ColorBlack
Mounting Locationno
Wirelessno
Networking ProtocolNDI PTZ,VISCA over IP, VISCA, Pelco-D, Pelco-P, CGI, HTTP, Onvif
ONVIFYes
Pan/TiltYes
Sensor & DetectorCMOS
Pixels2 MP
HD Resolution1080P
Lens TypeOptical Zoom Lens
Optical Zoom20x
Digital Zoom16x
Power over EthernetYes
Temperature-10°C ~ 40°C (14°F ~104°F)

Jautājumi par šo preci

How far can the 20x optical zoom lens reach before image quality drops?

The lens covers 4.42mm to 88.5mm with a maximum aperture of F1.8, giving 20x optical zoom before any digital crop.

What is the operating temperature range when the camera runs continuously?

Rated for -10°C to 40°C (14°F to 104°F) ambient temperature during sustained operation.

Which cables and mounts must I already have to install this camera?

You need a PoE-enabled network switch or injector, plus standard HDMI or 3G-SDI cables for video output; mounting hardware is not included.
