Compact black fanless aluminium mini PC with extensive rear I/O

partaker

partaker I20 barebone mini PC i5-6500T 16G 512G

SKU CH-75GK-75BN7

Fanless industrial mini PC with Intel Core i5-6500T, 16GB DDR4, 512GB SSD, dual LAN, HDMI, VGA, six COM ports, ten USB ports and a CAN interface

  • ColorBlack
  • CPU TypeIntel Core i5 6th Gen

CPU Type Intel Core i5

Group 16GB RAM / 512GB SSD

  • Fanless aluminium chassis runs silently in industrial settings
  • Intel Core i5 6500T quad-core reaches 3.1 GHz turbo for demanding workloads
  • 16 GB DDR4 2400 memory handles multitasking and fast data processing
  • 512 GB storage plus M.2, MSATA and dual 2.5 inch bays for flexible expansion
  • Ten USB ports, dual LAN, six COM and CAN bus connect diverse peripherals

Industrial fanless mini PC

The Partaker I20 is a new fanless mini PC built around an Intel Core i5 6500T processor with 16 GB of DDR4 memory and a 512 GB SSD. Its all-aluminium chassis operates silently across a wide temperature range and accepts a 12 V DC input with an optional 9 V to 36 V range. The system ships with Windows 11 Pro or Ubuntu Linux pre-installed.

Suited for automation and edge deployments

This unit serves integrators who need extensive serial I/O with six COM ports configurable for RS232, RS422 or RS485, dual independent displays via HDMI and VGA, dual Gigabit LAN and a dedicated CAN bus interface. Expansion is provided through one Mini PCIe slot supporting mSATA, a second Mini PCIe slot with an external SIM tray for wireless or cellular modules, and an optional M.2 slot. Buyers who require active cooling, higher single-thread performance or consumer-oriented features such as audio-centric codecs should look elsewhere.

Deciding spec: six configurable COM ports plus CAN

The combination of six hardware serial ports — two of them switchable between RS232, RS422 and RS485 — and a CAN 2.0A/B channel running at up to 1 Mbit/s determines whether this platform matches a machine-level communication requirement. No other single specification in the data sheet governs that integration decision.

Öne çıkanlar

  • Fanless aluminium chassis runs silently in industrial settings
  • Intel Core i5 6500T quad-core reaches 3.1 GHz turbo for demanding workloads
  • 16 GB DDR4 2400 memory handles multitasking and fast data processing
  • 512 GB storage plus M.2, MSATA and dual 2.5 inch bays for flexible expansion
  • Ten USB ports, dual LAN, six COM and CAN bus connect diverse peripherals

Teknik özellikler

ColorBlack
CPU TypeIntel Core i5 6th Gen

Bu modelin diğer sürümleri

Aynı seriden 5 tane daha

Aynı aile, farklı bellek, soğutucu veya frekans — karar vermeden önce karşılaştırın.

Bu ürünle ilgili sorular

How do I confirm the i5-6500T is running at its 2.5 GHz base and 3.1 GHz turbo after assembly?

Enter the BIOS on boot and verify the CPU reads Intel Core i5 6500T with base clock 2.5 GHz and max turbo 3.1 GHz; under load in Windows 11 Pro or Ubuntu the task manager should show the same frequencies.

What ships inside the I20 chassis and which parts must I source separately?

The unit includes the fanless aluminium case, motherboard with i5-6500T soldered, 16 GB DDR4 2133/2400 RAM installed, 512 GB MSATA SSD installed, two Intel i211-AT LAN ports, ten USB, six COM, HDMI, VGA, audio, GPIO, CAN and dual mini-PCIe/M.2 slots; you only add a 12 V DC power adapter and any optional 2.5" drive or wireless card.

The listing shows 16 GB RAM and 512 GB SSD — are there other memory or capacity versions I should consider?

This SKU is fixed at 16 GB DDR4 (the board maximum) and a 512 GB MSATA drive; the platform supports one DDR4 slot up to 16 GB and one MSATA plus optional 2.5" bays, so no larger RAM kit exists for this model.
