Green PCB expansion card with M.2 M-key slot and two 20-pin USB 3.2 Type-E headers

EN-Labs

EN-Labs M.2 M-key NVMe to 2× USB 3.2 Type-E 20-pin expansion card

SKU CH-PEYW-BDZD4

Adds two 10 Gbps USB 3.2 Type-E 20-pin headers to an M.2 M-key NVMe slot with 10 W power output

Add two front-panel USB-C ports from a single M.2 M-key NVMe slot
10 Gbps data throughput when connected to PCIe 3.0 or 4.0 NVMe
Each USB 3.2 Type-E header delivers up to 10 W (5 V / 2 A)
ASMedia ASM3142 controller handles dual 20-pin internal connections
Data-only design — no DisplayPort alt-mode or power-delivery charging

20,99 $

0.00026968 BTC με τη σημερινή ισοτιμία

Διαθέσιμο · αποστολή σήμερα

Το ταμείο κλειδώνει την ισοτιμία σας για 30 λεπτά.

Παράδοση προς Ηνωμένες Πολιτείες εκτίμηση

UPS Worldwide Expedited 3–6 εργάσιμες ημέρες 39,90 $
DHL Express Worldwide 2–3 εργάσιμες ημέρες 74,90 $

Προσθέστε 378,01 $ ακόμη και η βασική αποστολή γίνεται δωρεάν.

Οι εισαγωγικοί δασμοί επιβάλλονται κατά την άφιξη από τη χώρα σας.

Αποστολή αλλού

M.2 M-key NVMe to dual USB 3.2 Type-E adapter

This add-on card converts a single M.2 M-key NVMe slot into two internal USB 3.2 Type-E 20-pin headers. It is aimed at builders who need extra front-panel or rear-panel USB-C connectors and have a spare M.2 slot available. The ASMedia ASM3142 chipset handles the protocol conversion. No video or audio alternate modes are supported.

Dual 20-pin headers with 10 W power per port

Each Type-E header delivers up to 10 watts at 5 V 2 A, allowing high-power USB-C front-panel devices, hubs or card readers to operate without an external power brick. The 20-pin connectors match standard motherboard USB 3.2 internal header pinouts for straightforward cabling. Installation simply requires a compatible M.2 M-key slot and the supplied mounting screw.

Passive cooling with PCIe 3.0 or 4.0 NVMe source

The card draws power directly from the M.2 slot and uses no active cooling, so it adds no fan noise to the system. Maximum data throughput of 10 Gbps is achieved when the host slot provides PCIe 3.0 or 4.0 NVMe protocol bandwidth. Power draw scales with attached USB devices but remains within the slot’s standard delivery limits.

Βασικά χαρακτηριστικά

Add two front-panel USB-C ports from a single M.2 M-key NVMe slot
10 Gbps data throughput when connected to PCIe 3.0 or 4.0 NVMe
Each USB 3.2 Type-E header delivers up to 10 W (5 V / 2 A)
ASMedia ASM3142 controller handles dual 20-pin internal connections
Data-only design — no DisplayPort alt-mode or power-delivery charging

Προδιαγραφές

Δεν έχουν δημοσιευτεί ακόμη προδιαγραφές για αυτό το προϊόν.

Ερωτήσεις για αυτό το προϊόν

How fast can the USB 3.2 Type-E headers run and what limits them?

The two USB 3.2 Type-E headers share a 10 Gbps ceiling. To reach that speed the card must be plugged into a PCIe 3.0 or PCIe 4.0 NVMe M-key slot; a slower slot caps the throughput below 10 Gbps.

What motherboard slot and headers are required to install the card?

You need one free M.2 M-key NVMe slot on the motherboard and two internal USB 3.2 Type-E 20-pin headers to connect the front-panel or rear-panel cables.

How is the card installed and which step is often missed?

Insert the card into the M.2 M-key NVMe slot and secure it with the motherboard standoff screw, then attach both 20-pin cables to the motherboard's USB 3.2 Type-E headers; the step people forget is plugging in both power cables so each port can deliver 5 V 2 A.
