NEMIX RAM
NEMIX RAM 192GB (12x16GB) DDR5 4800 ECC RDIMM ASUS K14PA-U12
192 GB DDR5-4800 ECC registered server kit with twelve 16 GB modules built for the ASUS K14PA-U12 motherboard
- Capacity192GB (12 x 16GB)
- SpeedDDR5 4800 (PC5 38400)
- ECCYes
- Buffered/RegisteredRegistered
- ChipsetMajor OEM Samsung, Micron, Hynix
- Voltage1.10V
- 192 GB total capacity from twelve 16 GB modules
- DDR5 4800 speed with PC5-38400 bandwidth rating
- ECC registered design detects and corrects data errors
- 1 V operation lowers power draw per module
- Validated for ASUS K14PA-U12 with 128-core EPYC 9004
ASUS K14PA-U12 DDR5 RDIMM kit
This 192GB kit contains twelve 16GB DDR5 4800 ECC registered DIMMs built for the ASUS K14PA-U12 motherboard. It targets administrators scaling memory on 128-core AMD EPYC 9004 platforms.
Registered ECC limits at DDR5 4800
Registered DIMMs add a buffer that stabilises heavy loads but introduces one cycle of latency versus unbuffered modules. The JEDEC DDR5 4800 standard caps this kit at 4800 MT/s and CL40 timings.
Verify twelve-slot population rules
Confirm the K14PA-U12 supports twelve 1Rx8 modules per processor and that your BIOS revision enables full-speed operation with all slots filled. Check maximum capacity per channel before ordering.
Istaknuto
- 192 GB total capacity from twelve 16 GB modules
- DDR5 4800 speed with PC5-38400 bandwidth rating
- ECC registered design detects and corrects data errors
- 1 V operation lowers power draw per module
- Validated for ASUS K14PA-U12 with 128-core EPYC 9004
Specifikacije
| Brand | NEMIX RAM |
|---|---|
| Series | ASUS Server Motherboard Compatible Series Memory |
| Model | ASUS DDR5 4800MHZ ECC RDIMM Registered Server Memory |
| Part Number | MR38400-618K12 |
| Capacity | 192GB (12 x 16GB) |
| Speed | DDR5 4800 (PC5 38400) |
| ECC | Yes |
| Buffered/Registered | Registered |
| Chipset | Major OEM Samsung, Micron, Hynix |
| Voltage | 1.10V |
| Compatible System | ASUS |
| CAS Latency | CL40 |
| Heat Spreader | No |
| Type | 288-Pin DDR5 RDIMM |
| Rank | 1Rx8 |
| Features | DDR5 ECC Registered RDIMM Server Motherboard Compatible |
| Package Content | 192GB (12X16GB) DDR5 4800MHZ PC5-38400 1Rx8 1.1V CL40 288-PIN ECC RDIMM Registered Server Memory KIT |
Pitanja o ovom artiklu
Should I choose the 12-module 192GB kit or a smaller capacity for my ASUS K14PA-U12?
The 12-module kit provides 192GB total using 12x16GB RDIMMs, matching the 128-core AMD EPYC 9004 platform's memory channel count for balanced bandwidth across all channels.
What does the 4800 MT/s speed mean once installed in the server?
The modules run at DDR5 4800 (PC5-38400) with CL40 latency at 1.1V, delivering the rated transfer rate when the motherboard firmware configures the memory controllers for that speed.
How does the DDR5 288-pin RDIMM interface limit performance in this system?
The registered DDR5 RDIMM interface operates at 4800 MT/s with ECC enabled, and the 1Rx8 organisation on each 16GB module determines the maximum rank density the memory controller can address per channel.
