Eight green DDR4 RDIMM modules in anti-static tray

NEMIX RAM

NEMIX RAM 256GB (8x32GB) DDR4 3200 CL22 2Rx4 ECC RDIMM SuperMicro WRX80 memory upgrade

SKU CH-Y4VX-NFJKV

Eight 32 GB DDR4 3200 CL22 ECC registered DIMMs totalling 256 GB for SuperMicro WRX80 motherboards

  • Capacity256GB (8 x 32GB)
  • SpeedDDR4 3200 (PC4 25600)
  • ECCYes
  • Buffered/RegisteredRegistered
  • ChipsetMajor OEM Samsung, Micron, Hynix
  • Voltage1.20V

Capacity 256GB 8X32GB

Prikaži još 4 konfiguracija
  • 256 GB capacity scales memory-heavy workloads
  • DDR4 3200 speed feeds data to CPU cores
  • ECC registered design corrects errors for uptime
  • 2Rx4 organisation maximises density per channel
  • 2 V operation reduces server power draw

256GB DDR4 RDIMM kit for SuperMicro WRX80

This NEMIX RAM kit delivers 256GB across eight 32GB DDR4 3200 registered ECC modules built for the SuperMicro M12SWA-TF WRX80 motherboard. It targets IT professionals and workstation builders who need maximum supported capacity for virtualisation, rendering or large dataset workloads. The 2Rx4 organisation and 1.20V operation match the platform's registered memory requirements.

Sustained-load behaviour

Registered buffering reduces electrical load on the memory controller, allowing all eight slots to run at the rated 3200MT/s without signal degradation during long compute runs. ECC corrects single-bit errors on the fly, preventing silent data corruption in databases, scientific simulations or multi-day render jobs. CL22 latency is the standard timing for this density and speed class on WRX80.

Installation notes and common pitfalls

Modules are bare 288-pin RDIMMs without heat spreaders, so they fit tight DIMM spacing on the M12SWA-TF. Populate all eight slots identically; mixing ranks or capacities breaks the quad-channel topology and will halt POST. Verify the BIOS is current before install — early revisions may not initialise 256GB at 3200MT/s and can default to a lower speed.

Istaknuto

  • 256 GB capacity scales memory-heavy workloads
  • DDR4 3200 speed feeds data to CPU cores
  • ECC registered design corrects errors for uptime
  • 2Rx4 organisation maximises density per channel
  • 2 V operation reduces server power draw

Specifikacije

BrandNEMIX RAM
SeriesSuperMicro Server/Workstation Compatible Series Memory
ModelSuperMicro DDR4 3200MHZ ECC RDIMM Registered Server Memory
Part NumberMR25600-324K8
Capacity256GB (8 x 32GB)
SpeedDDR4 3200 (PC4 25600)
ECCYes
Buffered/RegisteredRegistered
ChipsetMajor OEM Samsung, Micron, Hynix
Voltage1.20V
Compatible SystemSupermicro
CAS LatencyCL22
Heat SpreaderNo
Type288-Pin DDR4 RDIMM
Rank2Rx4
FeaturesDDR4 ECC Registered RDIMM Server Motherboard Compatible
Package Content256GB (8X32GB) DDR4 3200MHZ PC4-25600 2Rx4 1.2V CL22 288-PIN ECC RDIMM Registered Server Memory KIT

Druge verzije ovog modela

još 5 u istoj seriji

Ista obitelj, različita memorija, hladnjak ili frekvencija — usporedite prije kupnje.

Pitanja o ovom artiklu

Does the 1.20 V registered DDR4 kit run cool enough for continuous 24/7 server workloads?

The modules operate at the standard DDR4 1.20 V and have no heat spreader, so they rely on the chassis airflow that SuperMicro WRX80 platforms already provide for sustained operation.

What must the system already provide for these 288-pin ECC RDIMMs to function?

A SuperMicro WRX80 motherboard with eight free DDR4 RDIMM slots, a CPU that supports registered ECC memory, and a BIOS version that recognises 32 GB 2Rx4 modules at 3200 MT/s.

Will the CL22 2Rx4 registered modules work alongside older DDR4 ECC RDIMMs already installed in the same WRX80 board?

Mixing ranks, speeds or latencies on a WRX80 platform can prevent the system from posting or force all channels down to the slowest common settings, so a full 256 GB kit is recommended instead of combining with existing DIMMs.
