Green rectangular DDR5 memory module with gold edge connector and black chips, no heat spreader

NEMIX RAM

NEMIX RAM 96GB DDR5 6400 CL52 2Rx4 1.1V ECC RDIMM Supermicro H14DSG-OD memory upgrade

SKU CH-6R8P-N78HX

96 GB DDR5 6400 ECC registered RDIMM with 2Rx4 rank and CL52 latency, validated for the Supermicro H14DSG-OD motherboard

  • Capacity96GB
  • Type288-Pin DDR5 RDIMM
  • SpeedDDR5 6400 (PC5 51200)
  • CAS LatencyCL52
  • Voltage1.10V
  • ECCYes
  • Exact-match 96GB DDR5-6400 CL52 2Rx4 RDIMM for full rated speed
  • Verified fitment for Supermicro H14DSG-OD 288-pin registered slots
  • Enterprise stability via registered ECC architecture correcting single-bit errors
  • Check your system manual for supported capacities and population rules
  • Lifetime replacement warranty with US-based technical support

96GB DDR5 ECC RDIMM upgrade

This 96GB DDR5 6400 CL52 registered ECC module is built for the Supermicro H14DSG-OD motherboard. It targets server administrators who need exact-match memory to populate every slot at full capacity without downclocking. The 2Rx4 rank and 1.1V operation match the board's native requirements. Builders using consumer UDIMM or SODIMM form factors cannot use this part.

Registered ECC with 2Rx4 organization

The single specification that decides fitment is the 288-pin registered ECC RDIMM design with 2Rx4 rank structure. This architecture offloads the memory controller so fully populated channels run at the rated 6400 speed while ECC corrects single-bit errors on the fly. A module lacking registration or ECC will not be recognized by this server platform.

Single-module kit with lifetime support

The package contains one 96GB DDR5 6400 CL52 1.1V RDIMM backed by a lifetime replacement warranty and free US-based technical support. No heat spreader is included, relying on server chassis airflow for cooling. Installers must still consult the motherboard manual for approved DIMM population order and maximum supported capacity per slot.

Istaknuto

  • Exact-match 96GB DDR5-6400 CL52 2Rx4 RDIMM for full rated speed
  • Verified fitment for Supermicro H14DSG-OD 288-pin registered slots
  • Enterprise stability via registered ECC architecture correcting single-bit errors
  • Check your system manual for supported capacities and population rules
  • Lifetime replacement warranty with US-based technical support

Specifikacije

BrandNEMIX RAM
SeriesNEMIX RAM Original Series Server Memory
ModelDDR5 ECC RDIMM Registered Server Memory
Part NumberMR51200-9624K1
Capacity96GB
Type288-Pin DDR5 RDIMM
SpeedDDR5 6400 (PC5 51200)
CAS LatencyCL52
Voltage1.10V
ECCYes
Buffered/RegisteredRegistered
Rank2Rx4
ChipsetMajor OEM Samsung, Micron, Hynix
Heat SpreaderNo
Compatible SystemSupermicro
FeaturesDDR5 ECC RDIMM Motherboard Compatible
Package Content96GB DDR5 6400MHz PC5-51200 2Rx4 1.1V 288-PIN ECC RDIMM KIT

Pitanja o ovom artiklu

What does the 6400 speed rating mean for actual throughput in a Supermicro H14DSG-OD server?

The DDR5 6400 modules transfer data at 6400 MT/s, matching the motherboard's maximum supported memory bus speed for full-rated bandwidth.

How does the PC5-51200 designation relate to the DDR5 interface on this motherboard?

PC5-51200 is the JEDEC module name for DDR5 6400; the Supermicro H14DSG-OD memory controller runs these RDIMMs at their rated 6400 MT/s.

What physical slot and clearance does the 288-pin RDIMM need in the H14DSG-OD chassis?

Each 288-pin Registered DIMM installs in a standard DDR5 RDIMM slot; the module has no heat spreader so it fits tight server DIMM cages without height conflicts.
