Silver 21.5 inch all-in-one panel PC with resistive touchscreen and fanless aluminum chassis

partaker

Partaker A17-PA-215TPC-CE5A(I34) 21.5" all-in-one PC

SKU CH-RZVF-TKE7T

21.5" IP65-rated industrial panel PC with Intel Core i3 4th Gen, 8 GB DDR3L, 256 GB SSD, resistive touch and fanless cooling

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i3 4th Gen
  • CPU Name1.90GHz
  • GPU/VGA TypeIntel HD Graphics 4400

GPU Intel HD Graphics 4400

Memory 8GB DDR3

  • 4GB DDR3
  • 8GB DDR3

SSD 256GB

HDD None

Precrtane verzije postoje, ali nisu dostupne ovdje.

  • IP65 front-panel protection resists dust and water ingress
  • Fanless aluminium-alloy cooling runs silently 24/7
  • 5-wire resistive touchscreen rated for 35 million touches
  • Intel Core i3 4th Gen with 8 GB DDR3 and 256 GB SSD
  • Wide 0–50 °C operating range suits harsh industrial sites

Industrial All-in-One Panel PC

The Partaker A17-PA-215TPC-CE5A(I34) is a 21.5" industrial all-in-one computer built for continuous operation. It combines an Intel Core i3 4th Gen processor at 1.90GHz with 8GB DDR3L memory and a 256GB mSATA SSD inside a fanless aluminum chassis. The front panel carries an IP65 rating and a high-temperature 5-wire resistive touchscreen rated for 35 million touches.

Replaces Legacy Panel-Mount PCs

This unit replaces older panel-mount systems that rely on active cooling or lower ingress protection. The jump is worth it when an application demands silent fanless operation, a wide 0–50°C operating range with SSD, and a 1920 x 1080 display with 250 cd/m² brightness. It also suits upgrades needing modern I/O such as HDMI, VGA, dual LAN, and 2 x COM ports alongside 2 x USB3.0 and 2 x USB2.0.

Verify Mounting Cut-Out and Power

Before ordering, confirm the 522 x 315mm panel cut-out matches your enclosure and that the 527.8 x 321 x 54.5mm overall dimensions fit the available depth. Ensure the site can supply 12V DC via the included 100–240V AC adapter and that the Mini PCIe slot with SIM holder meets any wireless expansion needs. The system ships with Windows 10 Pro 64-bit and supports Linux Ubuntu.

Istaknuto

  • IP65 front-panel protection resists dust and water ingress
  • Fanless aluminium-alloy cooling runs silently 24/7
  • 5-wire resistive touchscreen rated for 35 million touches
  • Intel Core i3 4th Gen with 8 GB DDR3 and 256 GB SSD
  • Wide 0–50 °C operating range suits harsh industrial sites

Specifikacije

ModelA17-PA-215TPC-CE5A(I34)-8G256G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i3 4th Gen
CPU Name1.90GHz
GPU/VGA TypeIntel HD Graphics 4400
Memory Capacity8GB DDR3
SSD256GB
HDDNo
Screen Size21.5"
TouchscreenYes

Druge verzije ovog modela

još 5 u istoj seriji

Ista obitelj, različita memorija, hladnjak ili frekvencija — usporedite prije kupnje.

Pitanja o ovom artiklu

What panel cut-out size does the 21.5" unit need for embedded mounting?

The embedded mounting cut-out is 522 x 315 mm. The front panel carries an IP65 rating and the chassis measures 527.8 x 321 x 54.5 mm overall.

How is the 12 V DC power connected and what step is often missed?

Connect the supplied 100-240 V AC adapter to the 12 V DC jack and secure the cable with the embedded buckle kits; the commonly missed step is enabling auto power-on after power failure in the BIOS.

Which storage drives can be replaced later and what are the limits?

One mSATA SSD and one 2.5" SATA SSD or HDD are user-replaceable; memory is a single SODIMM DDR3L 1333/1600 module with a maximum of 8 GB.
