Silver 12.1 inch all-in-one panel PC with resistive touchscreen and aluminium housing

partaker

partaker A2-PA-121TPC-CE5B(I34)-8G128G 12.1" all-in-one PC

SKU CH-0M4W-MFG4B

A 12.1" industrial panel PC with IP65 front protection, high-temperature five-wire resistive touchscreen, Intel Core i3 4th Gen CPU, 8GB DDR3L RAM, 128GB SSD, fanless aluminium chassis.

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i3 4th Gen
  • CPU Name1.90GHz
  • GPU/VGA TypeIntel HD Graphics 4400

GPU Intel HD Graphics 4400

Memory 8GB DDR3

SSD

HDD None

  • None
  • 1TB

Precrtane verzije postoje, ali nisu dostupne ovdje.

  • IP65 front-panel protection resists dust and water jets
  • 1-inch TFT LED display with 1024 x 768 resolution
  • Intel Core i3 4th Gen 1.90GHz CPU delivers responsive performance
  • 8GB DDR3L memory and 128GB SSD provide fast boot and multitasking
  • Fanless aluminium alloy chassis runs silently in industrial environments

Industrial 12.1-inch panel PC

The Partaker A2-PA-121TPC-CE5B(I34)-8G128G is a compact all-in-one computer built for embedded industrial use. It integrates a 12.1-inch TFT LED display with an IP65-rated front panel into a fanless aluminium chassis. An Intel Core i3 4th Gen processor at 1.90GHz with 8GB DDR3L memory and a 128GB mSATA SSD runs Windows 10 Pro. The unit operates from a 12V DC supply across a wide temperature range.

Suited for fixed automation and monitoring

This panel PC fits machine interfaces, kiosks and control cabinets that need a sealed resistive touchscreen and legacy I/O such as VGA, dual COM ports and dual USB 2.0 alongside USB 3.0 and HDMI. The fanless design and 0 to 50°C operating range with an SSD suit dusty or vibration-prone environments. Buyers who need a capacitive multi-touch screen, a larger display diagonal, or modern high-speed storage interfaces should look at other form factors.

12.1-inch IP65 resistive touchscreen

The display measures 12.1 inches with a 1024 x 768 resolution, 350 cd/m² brightness and a 1000:1 contrast ratio. Its high-temperature five-wire resistive layer is rated for 200 million touches and 86% transmittance, allowing reliable gloved operation in harsh conditions. The IP65 front seal protects internal components from water jets and dust ingress during wash-down or heavy industrial exposure.

Istaknuto

  • IP65 front-panel protection resists dust and water jets
  • 1-inch TFT LED display with 1024 x 768 resolution
  • Intel Core i3 4th Gen 1.90GHz CPU delivers responsive performance
  • 8GB DDR3L memory and 128GB SSD provide fast boot and multitasking
  • Fanless aluminium alloy chassis runs silently in industrial environments

Specifikacije

ModelA2-PA-121TPC-CE5B(I34)-8G128G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i3 4th Gen
CPU Name1.90GHz
GPU/VGA TypeIntel HD Graphics 4400
Memory Capacity8GB DDR3
HDDNo
Screen Size12.1"
TouchscreenYes

Druge verzije ovog modela

još 5 u istoj seriji

Ista obitelj, različita memorija, hladnjak ili frekvencija — usporedite prije kupnje.

Pitanja o ovom artiklu

What are the exact cut-out dimensions for the embedded mounting hole?

The embedded mounting hole requires an opening of 301 x 229 mm to fit the panel PC flush into a cabinet or enclosure.

Which step is often missed when installing the panel PC into an enclosure?

The embedded buckle kits included in the packing list must be fastened to the rear chassis to secure the unit; skipping this leaves the PC loose in the cut-out.

What is the rated backlight lifetime of the 12.1" display?

The TFT LED backlight is rated for a minimum of 30,000 hours of continuous operation before brightness degrades significantly.
