Silver 12.1 inch industrial all-in-one panel PC with IP65 front protection

partaker

Partaker A2-PA-121TPC-CE5B(J64)-16G256G1TB all-in-one PC

SKU CH-RARD-9M98V

12.1-inch IP65 industrial all-in-one with Intel Celeron J6412, 16GB DDR4, 256GB SSD plus 1TB HDD, resistive touchscreen and Windows 10 Pro

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeCeleron
  • CPU Name2.00GHz
  • GPU/VGA TypeIntel UHD Graphics
  • IP65 front panel resists dust and water jets
  • Fanless aluminium chassis runs silently from 0 to 50 °C
  • Intel Celeron J6412 up to 2.60 GHz drives industrial workloads
  • 16 GB DDR4 plus 256 GB SSD and 1 TB HDD store large datasets
  • 1″ resistive touchscreen rated for 200 million touches

Industrial panel PC for embedded control

The Partaker A2-PA-121TPC-CE5B(J64)-16G256G1TB is a 12.1 inch all-in-one computer built for industrial automation and embedded control tasks. It combines an Intel Celeron J6412 processor with 16GB DDR4 memory, a 256GB SSD and a 1TB HDD in a sealed aluminium chassis. The IP65-rated front panel and resistive touchscreen suit factory floors, kiosks and outdoor cabinets where dust and moisture are present. Windows 10 Pro is pre-installed for immediate deployment.

Fanless thermal design with wide temperature range

Passive cooling through the aluminium alloy housing eliminates moving parts and keeps acoustic output at zero during normal operation. The system is rated for continuous use from 0 to 50°C when running from the SSD and 0 to 40°C with the mechanical HDD active. Power is supplied through a 12V DC input that accepts 100-240V AC via the included adapter, drawing only the low wattage typical of the J6412 platform. The fanless construction also removes a common failure point in vibration-prone environments.

Expansion slots and mounting hardware included

A full-size Mini PCIe slot and an M.2 2280 SATA socket allow the addition of Wi-Fi, 4G or extra storage without external dongles. Three COM ports, two LAN ports, four USB 3.0 ports and HDMI provide direct connectivity for PLCs, barcode scanners, cameras and secondary displays. The box contains the panel PC, 12V power supply, AC power cord and embedded buckle kits for panel or wall mounting. A SIM slot is available as a customised option for cellular projects.

Istaknuto

  • IP65 front panel resists dust and water jets
  • Fanless aluminium chassis runs silently from 0 to 50 °C
  • Intel Celeron J6412 up to 2.60 GHz drives industrial workloads
  • 16 GB DDR4 plus 256 GB SSD and 1 TB HDD store large datasets
  • 1″ resistive touchscreen rated for 200 million touches

Specifikacije

ModelA2-PA-121TPC-CE5B(J64)-16G256G1TB
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeCeleron
CPU Name2.00GHz
GPU/VGA TypeIntel UHD Graphics
Memory Capacity16GB DDR4
SSD256GB
HDD1TB
Screen Size12.1"
TouchscreenYes

Druge verzije ovog modela

još 5 u istoj seriji

Ista obitelj, različita memorija, hladnjak ili frekvencija — usporedite prije kupnje.

Pitanja o ovom artiklu

How is the panel PC mounted in an embedded cut-out, and what size opening should be cut?

Cut a 301 x 229 mm opening and secure the unit with the supplied embedded buckle kits.

Which storage drives can be added or swapped later, and what are the limits?

One M.2 2280 SATA SSD and one 2.5" SATA SSD or HDD are supported; memory maxes at 32 GB DDR4.

At what temperature does the system throttle or shut down during continuous operation?

Operating range is 0–50 °C with the SSD installed and 0–40 °C when the 2.5" HDD is in use.
