Silver 12.1 inch fanless all-in-one panel PC with resistive touchscreen

partaker

partaker A2-PA-121TPC-CE5B(J64)-8G256G1TB 12.1" IP65 all-in-one PC

SKU CH-QAS8-6653A

A 12.1 inch IP65 industrial panel PC with Intel Celeron J6412, 8GB DDR4, 256GB SSD and 1TB HDD for embedded use

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeCeleron
  • CPU Name2.00GHz
  • GPU/VGA TypeIntel UHD Graphics
  • IP65 front panel resists dust and water ingress
  • 1 inch resistive touchscreen tested to 200 million touches
  • Intel Celeron J6412 up to 2.60 GHz fanless performance
  • 8 GB DDR4 with 256 GB SSD plus 1 TB HDD storage
  • VESA 75 mount with DC 12 V wide-range power input

12.1″ IP65 Industrial Panel PC

This 12.1 inch all-in-one computer combines an Intel Celeron J6412 processor, 8 GB DDR4 memory, a 256 GB SSD and a 1 TB HDD in a fanless aluminium chassis. The front panel meets IP65 protection and the resistive touchscreen is rated for high-temperature operation. Windows 10 Pro is pre-installed for immediate deployment.

Suited for embedded control and monitoring

The unit fits machine builders who need a compact, sealed display with multiple legacy ports — three COM ports, dual LAN and four USB 3.0 — and VESA 75 mounting. Buyers who require a larger screen, higher brightness or a different touch technology should consider other form factors.

1024 × 768 resistive touchscreen

The 12.1 inch TFT LED panel delivers a 1024 by 768 resolution with 350 cd/m² brightness and 80° viewing angles in all directions. The 5-wire resistive layer supports 200 million touches and 86 % transmittance, making it the decisive spec for gloved or stylus-driven industrial use.

Istaknuto

  • IP65 front panel resists dust and water ingress
  • 1 inch resistive touchscreen tested to 200 million touches
  • Intel Celeron J6412 up to 2.60 GHz fanless performance
  • 8 GB DDR4 with 256 GB SSD plus 1 TB HDD storage
  • VESA 75 mount with DC 12 V wide-range power input

Specifikacije

ModelA2-PA-121TPC-CE5B(J64)-8G256G1TB
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeCeleron
CPU Name2.00GHz
GPU/VGA TypeIntel UHD Graphics
Memory Capacity8GB DDR4
SSD256GB
HDD1TB
Screen Size12.1"
TouchscreenYes

Druge verzije ovog modela

još 5 u istoj seriji

Ista obitelj, različita memorija, hladnjak ili frekvencija — usporedite prije kupnje.

Pitanja o ovom artiklu

What panel cut-out size does the 12.1" unit need for embedded mounting?

The embedded opening hole is 301 x 229 mm, and the unit also supports VESA 75 mounting.

How is the resistive touch screen calibrated after the panel is powered on?

Windows 10 Pro includes the Tablet PC Settings calibration tool; run the 4-point or 9-point routine once the driver loads.

Which storage drive should be replaced first if the 1 TB HDD reaches its rated life?

The 2.5" SATA HDD is the only mechanical drive; swap it for another 2.5" SATA SSD or HDD when needed.
