Gray 21.5 inch industrial all-in-one with IP65 flat front resistive touch screen and fanless aluminum chassis

partaker

Partaker A30 21.5" All-in-One PC i5-7200U 32GB RAM 512GB SSD

SKU CH-5RCS-3RE7B

Industrial IP65 resistive touch all-in-one with fanless cooling, Intel Core i5-7200U, 32GB DDR4, 512GB SATA SSD, dual LAN, dual COM, four USB 3.0, HDMI, Mini PCIe expansion, and Windows 11 Pro

  • TypeAll-in-One PC
  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 7th Gen
  • CPU NameIntel Core i5-7200U

A30 21.5" Resistive I5 7200U 32GB RAM / 512GB SSD

  • IP65 front panel resists dust and water jets in harsh environments
  • Fanless aluminium cooling runs silently from -20 °C to 60 °C
  • Dual Gigabit LAN plus four USB 3.0 and two COM ports for industrial connectivity
  • Two Mini PCIe slots with SIM holder allow WiFi, BT or cellular expansion
  • Resistive touch rated for over 50 million touches ensures long service life

Industrial all-in-one for automation

The Partaker A30 is a 21.5-inch fanless panel PC with an IP65-rated flat front, Intel Core i5-7200U processor, 32GB DDR4-2133 memory and a 512GB SSD. It runs Windows 11 Pro on a 1920×1080 resistive touch screen rated for 50 million touches. The aluminium chassis operates silently from -20°C to 60°C.

Replaces legacy HMI terminals

This unit upgrades older operator panels that lack dual Gigabit LAN, four USB 3.0 ports, two RS232/485 COM ports and Mini PCIe expansion with a SIM slot. The jump is worth it when a project needs modern connectivity, wide-voltage 12V DC input with optional 9-36V support and remote-management features such as Wake on LAN and watchdog timer.

Limited by resistive touch and 7th-gen CPU

The resistive layer only registers single-touch input and reduces light transmission compared with capacitive alternatives. The dual-core processor and DDR4-2133 ceiling restrict multitasking headroom for contemporary SCADA visualisation. Expansion relies on Mini PCIe rather than newer M.2 or PCIe slots.

Istaknuto

  • IP65 front panel resists dust and water jets in harsh environments
  • Fanless aluminium cooling runs silently from -20 °C to 60 °C
  • Dual Gigabit LAN plus four USB 3.0 and two COM ports for industrial connectivity
  • Two Mini PCIe slots with SIM holder allow WiFi, BT or cellular expansion
  • Resistive touch rated for over 50 million touches ensures long service life

Specifikacije

TypeAll-in-One PC
Form FactorAll-in-One
ColorGray
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 7th Gen
CPU NameIntel Core i5-7200U
Screen Size21.5"
Screen TypeMulti-Touch Screen

Druge verzije ovog modela

još 5 u istoj seriji

Ista obitelj, različita memorija, hladnjak ili frekvencija — usporedite prije kupnje.

Pitanja o ovom artiklu

What are the embedded mounting cut-out dimensions for the 21.5" panel?

The embedded installation cut-out measures 528 mm by 320 mm, and the unit ships with four mounting clips for panel-mount fitting.

How is the resistive touch screen calibrated, and what is the common mistake?

Calibration is handled in Windows 11 Pro settings; the common mistake is pressing too hard with a fingernail instead of using a stylus or fingertip for accurate registration.

What storage drives can be replaced later, and how many slots exist?

One mSATA SSD slot and one 2.5" SATA bay are available; both drives are user-replaceable for capacity upgrades or failure recovery.
