Black rectangular video doorbell with 180 degree diagonal lens and separate chime unit

Reolink

Reolink Video Doorbell PoE 5MP 180° with Chime V2

SKU CH-N33C-NCA9Z

A 5 MP wired video doorbell with a 180° diagonal view, built-in chime, person detection and local storage with no monthly fee

  • ProtocolHTTPS, IPv4, UPNP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS,
  • TypeSecurity & Motion
  • ColorBlack
  • App-EnabledYes
  • Amazon Alexa CompatibilityYes
  • Google Assistant CompatibilityYes
  • 5MP 2K resolution captures sharp visitor detail
  • 180° diagonal view covers the whole porch area
  • PoE wiring delivers stable power and data
  • Humanoid detection reduces false alerts from passing traffic
  • Chime V2 with 10 tunes sounds indoors instantly

180° PoE Video Doorbell for wired homes

The Reolink Video Doorbell PoE is a wired security camera that replaces a traditional doorbell and connects through Power over Ethernet. It suits homeowners who want a permanent installation without battery maintenance and who prefer local storage over cloud subscriptions. The package includes a Chime V2 unit that plugs into a mains socket for audible alerts indoors.

5MP 4:3 sensor with 180° diagonal view

A 1/2.7" CMOS sensor captures 2560×1920 video at 20 frames per second through an f=2.26mm F=2.0 lens with IR cut. The 4:3 aspect ratio yields a 135° horizontal by 100° vertical field of view, covering a wide porch area from a single mounting point. A 15° wedge kit is supplied to adjust the viewing angle. Footage is encoded in H.264 and can be recorded continuously or on motion to a microSD card up to 256GB, a Reolink NVR or an FTP/NAS target. Humanoid detection filters reduce alerts from non-human movement.

PoE and 12–24V AC power with ONVIF support

The doorbell accepts IEEE802.3af PoE from a compatible switch or injector, 12–24V AC at 50/60Hz or 24V DC, and also draws power from Reolink PoE NVRs. No power supply is included in the box. Third-party NVRs are not supported. The device speaks HTTPS, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP and P2P for integration with compatible software. Alexa and Google Assistant voice control are available. A 1m network cable, jumper cables and an extension cable are provided for the initial wiring run.

Istaknuto

  • 5MP 2K resolution captures sharp visitor detail
  • 180° diagonal view covers the whole porch area
  • PoE wiring delivers stable power and data
  • Humanoid detection reduces false alerts from passing traffic
  • Chime V2 with 10 tunes sounds indoors instantly

Specifikacije

BrandReolink
ModelVideo Doorbell POE
Part NumberVideo Doorbell POE
ProtocolHTTPS, IPv4, UPNP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
TypeSecurity & Motion
ColorBlack
App-EnabledYes
Amazon Alexa CompatibilityYes
Google Assistant CompatibilityYes
ConnectivityWired
BatteryBattery not Included
SpecificationsImage Sensor
1/2.7" CMOS Sensor
Video Resolution
Default: 2560X1920 (5 megapixels) @20FPS
Lens
f=2.26mm F=2.0, with IR cut
Videoformat
H.264
Field of View
• Horizontal: 135°
• Vertical: 100°
• Diagonal: 180°
Pre-Motion Recording
Support
Audio
Two-way audio, noise reduction, echo suppression
Quick Replies
Support
FeaturesBrowsers Supported
Edge, Chrome, Firefox, Safari
OS Supported
PC: Windows, Mac OS; Smartphone: iOS, Android
Smart Alarm
Motion detection/person detection; visit notification
Recording Modes
Motion recording (default); 24/7 recording; scheduled recording
Dimensions133mm(H) x 48mm(W) x 23mm(T)
Weight96g
Package ContentsReolink Video Doorbell PoE ×1
Reolink Chime ×1
Mounting Plate ×1
Wedge ×1
Jumper Cables ×1
Extension Cable ×1
1m Network Cable ×1
Quick Start Guide ×1

Pitanja o ovom artiklu

Will the 180° diagonal field of view cover the same entryway my old 135° horizontal camera watched?

The doorbell gives 180° diagonal, 135° horizontal and 100° vertical coverage; the included 15° wedge lets you angle it for the best match.

How can I confirm the 5MP 2560×1920 video is recording correctly after installation?

Open the Reolink app or a supported browser — Edge, Chrome, Firefox or Safari — and check the live view; motion clips appear in the timeline when humanoid detection triggers.

Does the box contain a PoE injector or power supply for the 802.3af connection?

The package includes the doorbell, Chime V2, mounting plate, 15° wedge, jumper cables, extension cable, 1 m network cable and quick start guide; a PoE switch, injector or 12-24 V AC / 24 V DC supply must be bought separately.
