Grey ATX power supply unit with 80mm fan and built-in cables

Replace Power

Replace Power HP A465w A475c A500n A500y A510e A510n A518x A520n power supply

SKU CH-5S8C-093HB

A reduced-depth ATX power supply with a 24-pin motherboard connector, three SATA connectors, two Molex connectors, a 4-pin CPU connector and a floppy connector.

  • ColorGrey
  • TypeATX
  • Fans1
  • Weight4
  • Fits compact cases with 5.86 inch depth
  • Delivers 280 watts continuous for stable operation
  • Powers multiple drives via three SATA connectors
  • Runs on 110 or 220 volt mains worldwide
  • Low ripple and noise protects sensitive components

Replacement Power Supply for HP Desktops

This unit replaces the original power supply in HP models A465w A475c A500n A500y A510e A510n A518x A520n. It fits a standard ATX slot while the reduced depth increases case compatibility. The grey enclosure uses a single 80 mm fan for cooling and includes a fixed cable set with a 20+4 pin motherboard connector, a 4 pin CPU connector, three SATA connectors, two Molex connectors and one floppy connector.

Sustained Load Behaviour

The supply delivers a continuous 280 watts across the +3.3 V +5 V +12 V1 +12 V2 -12 V and +5 VSB rails with a peak capacity of 420 watts. Low ripple and noise specifications help maintain stable voltages during extended operation. Hold-up time is at least 17 ms at nominal input so brief mains interruptions do not immediately drop the output. Rise time stays below 70 ms ensuring smooth start-up under load.

Thermals Noise and Power Draw

An 80 mm fan provides airflow for long-life performance while keeping acoustic output low in normal use. The unit accepts AC input from 110 V to 220 V at 47 Hz to 63 Hz making it suitable for worldwide mains without a selector switch. Hi-Pot testing and ROHS CE compliance confirm electrical safety and environmental standards. Power factor and efficiency figures are not supplied.

Istaknuto

  • Fits compact cases with 5.86 inch depth
  • Delivers 280 watts continuous for stable operation
  • Powers multiple drives via three SATA connectors
  • Runs on 110 or 220 volt mains worldwide
  • Low ripple and noise protects sensitive components

Specifikacije

BrandReplace Power
ModelHP A465w A475c A500n A500y A510e A510n A518x A520n
ColorGrey
TypeATX
Fans1
Weight4

Pitanja o ovom artiklu

How much heat and noise does the 80 mm fan produce when the 280 W unit runs all day?

The 80 mm fan is designed for stability and long-life performance; the unit is highlighted for low ripple and noise during continuous operation.

Which existing cables or connectors must my HP desktop already have for this 20+4 pin ATX supply to work?

Your system needs a standard 20+4 pin motherboard header, a 4-pin CPU power header, plus SATA 15-pin or Molex 4-pin drive connectors matching the three SATA and three Molex leads supplied.

Will the reduced 5.86 inch depth fit alongside the original mounting brackets in an older HP A500n chassis?

Yes, the reduced depth is specifically intended for increased compatibility with branded desktops such as the listed HP models.
