Compact black-grey aluminum mini PC, book-style form factor, single-side ports

partaker

Partaker I37 barebone mini PC Core i7-1255U 64GB RAM 1TB SSD

SKU CH-HN18-7JX55

Industrial mini PC with Core i7-1255U, 64 GB DDR5, 1 TB SSD, four Gigabit LAN ports, dual DisplayPort, isolated RS485 and GPIO, 12-24 V DC input, -20 to 60 °C operation

  • ColorBlack gray
  • CPU TypeIntel Core i7 12th Gen

I37 CPU I7 1255U 64GB RAM / 1TB SSD

  • 10 cores and 12 threads reach 4.7 GHz for demanding compute tasks
  • 64 GB DDR5 4800 MHz memory handles large workloads without bottlenecks
  • 4 Gigabit LAN ports including vPro support enable reliable network redundancy
  • 2 isolated RS485 and 8 channel isolated GPIO connect industrial equipment safely
  • 12 to 24 V DC wide input and -20 to +60 °C operation suit harsh environments

Compact Industrial Mini PC

The Partaker I37 barebone delivers a 12th Generation Intel Core i7-1255U processor with 10 cores and 12 threads in a book-style aluminium chassis. It arrives populated with 64GB of DDR5 4800MHz memory and a 1TB SSD, targeting integrators who need a ready-to-deploy fan-cooled platform for automation, AGV or edge-computing workloads.

Thermals and Power in Use

Active cooling keeps the system stable across a -20°C to +60°C operating range while drawing power from a 12-24V DC Phoenix connector. The all-aluminium enclosure dissipates heat without acoustic intrusion, supporting continuous 24/7 operation in surface-airflow environments.

Bundled Extras and Their Impact

A wall-mount bracket is included for immediate installation on DIN-rail or flat surfaces. Onboard TPM 2.0, watchdog, wake-on-LAN, PXE and auto power-on firmware features reduce integration effort for unattended industrial deployments.

Erősségek

  • 10 cores and 12 threads reach 4.7 GHz for demanding compute tasks
  • 64 GB DDR5 4800 MHz memory handles large workloads without bottlenecks
  • 4 Gigabit LAN ports including vPro support enable reliable network redundancy
  • 2 isolated RS485 and 8 channel isolated GPIO connect industrial equipment safely
  • 12 to 24 V DC wide input and -20 to +60 °C operation suit harsh environments

Műszaki adatok

ColorBlack gray
CPU TypeIntel Core i7 12th Gen

A modell további verziói

5 további ebben a termékcsaládban

Ugyanaz a termékcsalád, eltérő memória, hűtés vagy órajel — hasonlítsa össze, mielőtt dönt.

Kérdések a termékről

How do I install the I37 and which step is often missed?

Mount the 172*136*50 mm aluminum chassis using the included wall bracket, connect the 4-pin Phoenix DC 12 V 24 V supply, then attach the 4× Intel i210-AT/i219-LM LAN cables and 2× DisplayPort cables; the step often missed is securing the 3-pin Phoenix connectors for the isolated RS485 and optional CAN buses so they do not vibrate loose.

What maintenance or replacement will the I37 need later?

The 2× DDR5 4800 MHz SODIMM modules (max 64 GB) and the M.2 2280 SATA or NVME SSD plus mSATA drive are the only user-replaceable parts; the soldered Core i7-1255U CPU and the Intel Iris Xe graphics are not serviceable, and the internal fan (when fitted) may need cleaning or replacement after extended 24/7 operation.

What limit appears first under sustained load on the I37?

The chassis is rated for -20°C to +60°C surface air flow; under continuous full-load the internal temperature will hit the +60°C ceiling before the 12-24 V DC input or the 6× USB 3.0 ports reach their limits, so sustained performance depends on keeping ambient airflow within that 60°C maximum.
