Silver 4U rackmount chassis with sixty 3.5-inch hot-swap drive bays front and rear

ASRock Rack

ASRock Rack 4U60L8E-GENOA/2T barebone server 4U 60-bay 800W

SKU CH-AJAH-F3MVN MPN 4U60L8E-GENOA/2T

A 4U barebone server chassis with 60 hot-swap 3.5-inch SATA/SAS bays, eight 2.5-inch NVMe bays, four PCIe 5.0 x16 slots, dual 10 Gigabit Ethernet.

  • Form Factor4U Rackmount
  • WorkloadGeneral Purpose Server
  • CPU TypeAMD EPYC 9005 & 9004 Series
  • CPU SocketSocket SP5
  • Installed CPUNo CPU Installed
  • Max Processors1
  • 60 hot-swap 3.5" bays for massive storage capacity
  • 8 NVMe U.2 bays with PCIe 5.0 x4 speed
  • 4 FHHL PCIe 5.0 x16 slots for GPU or NIC expansion
  • Dual 10 GbE Intel X550-AT2 ports for high-throughput networking
  • 2+2 redundant 800 W 80 PLUS Platinum power supplies

4U barebone with 60 hot-swap bays

This 4U rackmount barebone targets organisations that need dense 3.5-inch storage in a single-socket AMD EPYC platform. It ships without a processor or memory so integrators can choose EPYC 9004, 9005 or 97x4 series CPUs up to 270W TDP. The chassis delivers 60 hot-swap SATA/SAS bays plus eight 2.5-inch NVMe bays for mixed workloads.

4 TB DDR5 ceiling and PCIe 5.0 headroom

Eight DDR5 4800 RDIMM slots support up to 4 TB of registered memory in a one-DIMM-per-channel layout. Four full-height half-length PCIe 5.0 x16 slots provide expansion bandwidth for accelerators or networking cards. Two M.2 PCIe 5.0 x4 sockets add fast boot or cache devices without consuming a PCIe slot.

Redundant 800W Platinum CRPS and 10GbE

A 2+2 CRPS 800W 80-PLUS Platinum power supply arrangement supplies N+N redundancy for continuous operation. Four hot-swap 80x38mm PWM fans cool the dense drive population. Dual RJ45 10 Gigabit ports from the Intel X550-AT2 controller handle high-throughput networking. Front-panel buttons and LEDs give direct power, reset, identification and fault status.

Helstu kostir

  • 60 hot-swap 3.5" bays for massive storage capacity
  • 8 NVMe U.2 bays with PCIe 5.0 x4 speed
  • 4 FHHL PCIe 5.0 x16 slots for GPU or NIC expansion
  • Dual 10 GbE Intel X550-AT2 ports for high-throughput networking
  • 2+2 redundant 800 W 80 PLUS Platinum power supplies

Tæknilýsing

BrandASRock Rack
Model4U60L8E-GENOA/2T
Form Factor4U Rackmount
WorkloadGeneral Purpose Server
CPU TypeAMD EPYC 9005 & 9004 Series
CPU SocketSocket SP5
Installed CPUNo CPU Installed
Max Processors1
CPU FeaturesThermal Design Power Up to 270W
Installed Memory SizeNo Memory Installed
Max Memory Supported4TB
Memory Type SupportedDDR5 4800
RegisteredYes
Installed HDDNo Storage Installed
PCI Express4 FHHL PCIe5.0 x16
First LANIntel X550-AT2
Max. LAN Speed10 Gigabit
ButtonsSystem Power ON/OFF, System Reset, ID
LEDsPower, HDD Activity, LAN Activity, System Fault, ID
Max. Power2+2 CRPS 800W 80-PLUS Platinum
BIOS FeaturesAMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM
ASRock Rack Instant Flash, ACPI 6.4 and abouve compliance wake up events, SMBIOS 3.5.0 and above, Plug and Play(PnP)
Fans4 PWM Hot-swap 80x38mm fans
Hardware MonitorCPU, MB, TR1 Temperature sensing
TemperatureOperation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C
HumidityNon operation humidity: 20% ~ 90% ( Non condensing)
Dimensions6.9" x 33.5" x 17.1"
Sendingarþyngd46.68 kg
Stærð sendingar1135 × 632 × 411 mm

Spurningar um þessa vöru

Will my existing 3.5" SATA drives work in the 60 hot-swap bays of this 4U60L8E-GENOA/2T?

Yes, the 60 hot-swap bays accept 3.5" SATA drives as well as SAS drives, so current SATA media can be installed directly.

Which front-panel LEDs confirm the 4U60L8E-GENOA/2T is operating normally after power-on?

The Power LED stays on, HDD Activity and LAN Activity blink during use, while System Fault and ID remain off when everything is healthy.

Does the 4U60L8E-GENOA/2T ship with a CPU, memory modules or drive trays, and what must I purchase separately?

The barebone includes the chassis, 2+2 redundant 800W 80-PLUS Platinum power supplies and four hot-swap 80x38mm fans; CPU, DDR5 4800 RDIMMs and all drive trays are not included.
