Two green 240-pin DDR3 DIMMs with gold contacts and black chips

Computer Memory Solutions

Computer Memory Solutions CM2078728500ECCRQR4H 32GB (2x16GB) DDR3 1066 ECC Registered memory upgrade

SKU CH-8GPH-WYJTG

Two 16 GB DDR3 1066 ECC registered DIMMs totalling 32 GB for Dell PowerEdge R610 servers

  • Capacity32GB (2 x 16GB)
  • Type240-Pin DDR3 SDRAM
  • SpeedDDR3 1066 (PC3 8500)
  • CAS LatencyCL7
  • Timing7-7-7
  • Voltage1.5V
  • 32 GB total capacity from two 16 GB modules
  • Registered ECC DDR3 ensures data integrity for servers
  • Tested compatible with Dell PowerEdge R610
  • PC3-8500 rated at 1066 MHz with CL7 timing
  • Kit of two matched DIMMs for dual-channel operation

Server-Specific DDR3 Upgrade

This 32 GB kit contains two 16 GB registered ECC DIMMs built for the Dell PowerEdge R610. It delivers 1066 MHz DDR3 operation with CL7 timing at 1.5 V. The modules are intended for server workloads that require error-correcting memory.

Registered Quad-Rank Constraint

Each DIMM uses a 4Rx4 organisation, so the R610 chipset limits the first triple-channel bank to 1066 MHz and drops a second bank to 800 MHz. The third bank must stay empty, making registered quad-rank layout the single specification that decides compatibility.

Capacity and Headroom

The kit provides 32 GB toward the system maximum of 192 GB with registered DIMMs across 12 sockets. It suits virtualisation or database tasks that fit within this headroom, while larger datasets would need additional sockets and CPUs.

Helstu kostir

  • 32 GB total capacity from two 16 GB modules
  • Registered ECC DDR3 ensures data integrity for servers
  • Tested compatible with Dell PowerEdge R610
  • PC3-8500 rated at 1066 MHz with CL7 timing
  • Kit of two matched DIMMs for dual-channel operation

Tæknilýsing

BrandComputer Memory Solutions
ModelCM2078728500ECCRQR4H
Capacity32GB (2 x 16GB)
Type240-Pin DDR3 SDRAM
SpeedDDR3 1066 (PC3 8500)
CAS LatencyCL7
Timing7-7-7
Voltage1.5V
ECCYes
Buffered/RegisteredRegistered
Rank4Rx4
ChipsetMajor Brand Chipset
Heat SpreaderBased on Current Inventory (If Required Please Contact)
Compatible SystemDell Poweredge R610
Package Content2 Memory RAM Sticks

Spurningar um þessa vöru

How does the 1066 MHz speed behave once the modules are installed in a PowerEdge R610?

The modules run at 1066 MHz in the first triple-channel bank; adding quad-rank modules to the second bank drops the speed to 800 MHz and the third bank must stay empty.

What does the PC3-8500 rating limit in practice?

PC3-8500 caps the data rate at 1066 MT/s, so the memory cannot exceed that transfer speed even if the platform supports 1333 MT/s.

What physical slot and form factor do these 16 GB sticks need to fit the R610?

Each stick is a 240-pin DDR3 registered DIMM, matching the R610's 240-pin DDR3 slots.
