Silver 1U rack server front with four 3.5-inch drive bays

HP

HP ProLiant DL360 Gen9 1U Rack Server E5-2620 v3 2.4GHz 64GB 2x 300GB 15K SAS H240ar

SKU CH-EE7X-PXYJH

1U rack server with one Xeon E5-2620 v3 2.4GHz six-core CPU, 64GB DDR4 ECC, two 300GB 15K SAS drives and H240ar RAID controller

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610
  • Six-core Xeon at 2.4 GHz handles multi-thread workloads
  • 64 GB DDR4 ECC memory supports virtualisation density
  • Two 300 GB 15K SAS drives deliver fast I/O
  • H240ar controller enables RAID 0/1/5/6/10/50/60
  • Dual 500 W redundant power supplies maintain uptime

1U Rack Server with Xeon E5-2620 v3

The HP ProLiant DL360 Gen9 is a 1U rack server built for space-constrained data centres. It arrives with a single Intel Xeon E5-2620 v3 six-core processor running at 2.4GHz and 64GB of DDR4 ECC registered memory. Redundant hot-swap 500W power supplies support continuous operation. The system uses the Intel C610 chipset and includes a Matrox G200 graphics controller for basic video output.

Suited for virtualisation hosts; not for GPU compute

This server suits organisations needing dense virtualisation hosts or memory-heavy applications within a single rack unit. The 24 DIMM slots allow memory expansion up to the 64GB installed limit with the current single-processor configuration. Buyers who need GPU-accelerated workloads should look elsewhere, as the Matrox G200 provides only basic management display output. The four LFF drive bays limit internal storage density compared to small-form-factor alternatives.

2x 300GB 15K SAS drives on H240ar controller

Primary storage consists of two HP 300GB 15K 6Gbps 3.5-inch SAS drives connected to the Smart HBA H240ar controller. The H240ar provides 12Gb SAS and 6Gb SATA connectivity with RAID 0, 1, 5, 6, 10, 50, and 60 support. Two additional LFF bays remain open for capacity expansion. No operating system is included, so the buyer must supply their own hypervisor or OS licences.

Helstu kostir

  • Six-core Xeon at 2.4 GHz handles multi-thread workloads
  • 64 GB DDR4 ECC memory supports virtualisation density
  • Two 300 GB 15K SAS drives deliver fast I/O
  • H240ar controller enables RAID 0/1/5/6/10/50/60
  • Dual 500 W redundant power supplies maintain uptime

Tæknilýsing

BrandHP
SeriesProLiant
ModelProliant DL360 G9
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity64GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots24
Storage ControllerHP Smart HBA H240ar Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media DrivesNone
GPU TypeMatrox G200
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports4 x Ports
Expansion SlotsPrimary Riser: 2 PCIe 3.0 Slots (1 & 2) available: 1x Full-Height Half Length, 1x Half-Lenth Half Height. Optional PCIe 3.0 slot 3 - Full-Height Half Height (Secondary PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Aðrar útgáfur af þessari vöru

5 í viðbót í sama vöruflokki

Sama fjölskylda, mismunandi minni, kælingu eða klukkuhraða — berðu saman áður en þú ákveður þig.

Spurningar um þessa vöru

What ships with the HP ProLiant DL360 Gen9 and what must I add?

The server arrives with one Xeon E5-2620 v3 at 2.4 GHz, 64 GB DDR4 already installed across 24 DIMM slots, two 300 GB 15 K SAS drives in the four 3.5-inch bays, an H240ar controller supporting RAID 0/1/5/6/10/50/60, dual 500 W redundant supplies and a Matrox G200 GPU. No operating system is included.

Which memory capacity should I select for this DL360 Gen9?

The board offers 24 DDR4 slots and the Xeon E5-2620 v3 supports up to 64 GB at 2400 MT/s, which is already populated. Choose this 64 GB configuration if the current capacity meets the workload; otherwise a second processor would be required to reach higher totals.

What does the 2.4 GHz Xeon E5-2620 v3 deliver in this 1U rack server?

The six-core processor provides 12 threads via hyper-threading at 2.4 GHz base frequency, driving the installed 64 GB DDR4 and the H240ar 12 Gb SAS controller for database, virtualization or general compute tasks in a 1U form factor.
