Black tower server chassis with three front 3.5-inch hot-swap drive bays and blue handles

iStarUSA Inc.

iStarUSA Inc. S-35-3M1BL server chassis, black, mini-ITX, 3× 3.5″ hotswap bays

SKU CH-QJ4Q-VWHZ2 MPN S-35-3M1BL

Compact tower chassis holds three hot-swap 3.5″ drives plus one 2.5″ bay for mini-ITX builds

  • Chassis TypeTower
  • ColorBlack
  • Case MaterialSECC
  • Motherboard CompatibilityMini ITX
  • External 3.5" Drive Bays3
  • Internal 2.5" Drive Bays1

Model S-35-3M1BL

  • Three 3.5″ hotswap bays let you swap drives without downtime
  • Mini-ITX support fits a full server board in a compact tower
  • 0 Gb/s SATA and SAS compatibility keeps storage fast and flexible
  • Front USB 2.0 ports give quick access for peripherals or boot media
  • Heavy-duty SECC steel with 4 mm aluminium front panel protects drives in demanding environments

Compact Storage Tower

The iStarUSA S-35-3M1BL is a black tower chassis built for Mini ITX motherboards and focused on dense storage. It provides three external 3.5-inch hot-swap bays and one internal 2.5-inch bay. The SECC steel construction and 4mm aluminium front panel give a rigid frame for always-on storage workloads.

Tool-Less Drive Access

Drives slide into the front bays without screws and lock via blue handles for quick swaps. The single expansion slot limits add-in cards to one low-profile device. Installers must verify that their Mini ITX board aligns with the rear I/O cutout and that the chosen flex power supply fits the internal cavity before closing the case.

Pre-Build Checklist

Confirm the motherboard is Mini ITX form factor and that the power supply is a compatible flex unit. The chassis supports 6.0Gb/s SATA and SAS hard drives only; other drive interfaces are not supported. Front connectivity is limited to two USB 2.0 ports and an optional 120mm fan can be added for extra airflow.

Helstu kostir

  • Three 3.5″ hotswap bays let you swap drives without downtime
  • Mini-ITX support fits a full server board in a compact tower
  • 0 Gb/s SATA and SAS compatibility keeps storage fast and flexible
  • Front USB 2.0 ports give quick access for peripherals or boot media
  • Heavy-duty SECC steel with 4 mm aluminium front panel protects drives in demanding environments

Tæknilýsing

BrandiStarUSA
ModelS-35-3M1BL
Chassis TypeTower
ColorBlack
Case MaterialSECC
Motherboard CompatibilityMini ITX
External 3.5" Drive Bays3
Internal 2.5" Drive Bays1
Expansion Slots1
Front Ports2 x USB 2.0
FeaturesThe external multi-bay tower series are designed specially for storage applications.
The wide variety of the tower with hard drive cages is able to easily max the hard drive capacity up to 3 bays for storing mass data.
Optional 120mm cooling fan can be added to enhance the ventilation inside.
The external NAS tower chassis with solid construction is a cost-effective and flexible solution for your critical data storage.
Sleek Front Panel with Power On Button
Support 6.0Gb/s SATA/SAS HDDs
Compatible with Flex Power Supply
Heavy Duty SECC Construction
Support Standard I/O Slot
Blue HDD
Dimensions8.90" x 8.68" x 12.76"
Sendingarþyngd8.17 kg
Stærð sendingar381 × 279 × 254 mm

Aðrar útgáfur af þessari vöru

3 í viðbót í sama vöruflokki

Sama fjölskylda, mismunandi minni, kælingu eða klukkuhraða — berðu saman áður en þú ákveður þig.

Spurningar um þessa vöru

How can I confirm the three 3.5″ hotswap bays are operating correctly after installation?

Insert drives into each bay, verify they appear in the BIOS or OS, and check that the front panel activity LEDs blink during read or write operations.

What comes with the chassis and which parts must I purchase separately?

The chassis includes the tower case with three 3.5″ hotswap bays, one internal 2.5″ bay, two front USB 2.0 ports, and a single expansion slot; you must supply a Mini ITX motherboard, drives, a Flex power supply, and an optional 120 mm cooling fan.

Which version of the S-35-3M1BL should I choose for maximum 3.5″ drive capacity?

This model is the only version offered and provides exactly three 3.5″ hotswap bays, so it already delivers the highest drive capacity available in this chassis line.
