Four green DDR5 RDIMM modules in anti-static packaging

NEMIX RAM

NEMIX RAM DDR5 5600 CL46 128GB 4x32GB ECC RDIMM memory upgrade for GIGABYTE MS34-CP0

SKU CH-J9PP-RJP75

128 GB DDR5 5600 registered ECC RDIMM kit of four 32 GB modules at 1.1 V CL46 validated for the GIGABYTE MS34-CP0 motherboard

  • Capacity128GB (4 x 32GB)
  • Type288-Pin DDR5 RDIMM
  • SpeedDDR5 5600 (PC5 44800)
  • CAS LatencyCL46
  • Voltage1.10V
  • ECCYes

Size 128GB 4X32GB

Sjá 18 stillingar til viðbótar
  • 128 GB kit (4 × 32 GB) provides high-density server memory
  • DDR5-5600 PC5-44800 speed runs at rated frequency
  • CL46 latency at 1.10 V matches controller timing
  • ECC and registered design corrects errors and buffers signals
  • 288-pin RDIMM form factor fits GIGABYTE MS34-CP0 motherboard

Exact-fit DDR5-5600 ECC RDIMM kit

This 128GB kit contains four 32GB DDR5-5600 Registered ECC RDIMMs specified at CL46 and 1.1V. It is built for the GIGABYTE MS34-CP0 motherboard and matches the board's required 288-pin RDIMM form factor, rank layout and timing profile.

Registered DDR5 population rules

Registered architecture buffers the address and command bus so the memory controller can drive all four slots at the rated 5600MT/s without signal degradation. The motherboard's validated population order and maximum supported capacity per slot still govern how many modules can be installed and at what speed they will operate.

Bare-module construction for dense servers

The modules ship without heat spreaders, keeping the profile low enough for tight 1U or blade chassis where airflow passes directly over the DRAM. The 288-pin RDIMM keying prevents accidental insertion into UDIMM or SODIMM slots, and the 2Rx8 organisation is recognised by the platform's memory controller during POST.

Helstu kostir

  • 128 GB kit (4 × 32 GB) provides high-density server memory
  • DDR5-5600 PC5-44800 speed runs at rated frequency
  • CL46 latency at 1.10 V matches controller timing
  • ECC and registered design corrects errors and buffers signals
  • 288-pin RDIMM form factor fits GIGABYTE MS34-CP0 motherboard

Tæknilýsing

BrandNEMIX RAM
SeriesNEMIX RAM Original Series Server Memory
ModelDDR5 ECC RDIMM Registered Server Memory
Part NumberMR44800-328K4
Capacity128GB (4 x 32GB)
Type288-Pin DDR5 RDIMM
SpeedDDR5 5600 (PC5 44800)
CAS LatencyCL46
Voltage1.10V
ECCYes
Buffered/RegisteredRegistered
Rank2Rx8
ChipsetMajor OEM Samsung, Micron, Hynix
Heat SpreaderNo
Compatible SystemGIGABYTE
FeaturesDDR5 ECC RDIMM Motherboard Compatible
Package Content128GB 4X32GB DDR5 5600MHz PC5-44800 2Rx8 1.1V 288-PIN ECC RDIMM KIT

Aðrar útgáfur af þessari vöru

5 í viðbót í sama vöruflokki

Sama fjölskylda, mismunandi minni, kælingu eða klukkuhraða — berðu saman áður en þú ákveður þig.

Spurningar um þessa vöru

Should I choose this 128GB kit or a smaller capacity for my GIGABYTE MS34-CP0?

This 128GB kit provides four 32GB modules. Select it when your workload needs the full capacity and your motherboard manual confirms all four slots can be populated with 2Rx8 Registered DIMMs at 5600MHz.

What does the 5600MHz rating deliver once installed in the server?

The memory runs at DDR5 5600 with CL46 latency and 1.10V. In a fully populated configuration the Registered design keeps every slot stable at that rated speed without downclocking.

How does the 288-pin RDIMM interface limit or enable performance on this board?

The 288-pin Registered ECC form factor is required by the MS34-CP0. It allows full-capacity operation across all channels while ECC corrects single-bit errors in real time.
