Silver 12.1 inch industrial all-in-one panel PC with resistive touchscreen

partaker

Partaker A2 12.1" All-in-One PC Intel Core i5 3rd Gen 1.70GHz 4GB DDR3 64GB SSD

SKU CH-8XM0-Q6SY7

Compact 12.1" industrial panel PC with IP65 front protection, Intel Core i5 1.70GHz, 4GB DDR3, 64GB SSD, resistive touchscreen, and fanless aluminium housing

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 3rd Gen
  • CPU Name1.70GHz
  • GPU/VGA TypeIntel HD Graphics

GPU Intel HD Graphics

Memory 4GB DDR3

  • 4GB DDR3
  • 8GB DDR3

SSD 64GB

  • 64GB
  • 256GB
  • 512GB

HDD None

  • None
  • 1TB

Yfirstrikaðar útgáfur eru til, en ekki til hér.

  • IP65 front-panel protection for harsh environments
  • 1" resistive touch screen rated for 200 million touches
  • Fanless aluminium chassis runs silently from 0 °C to 50 °C
  • Intel Core i5 third-gen with 4 GB DDR3 and 64 GB SSD
  • VESA 75 mount plus HDMI, VGA, LAN and dual COM ports

Industrial 12.1″ All-in-One

The Partaker A2 is a compact panel PC built around a 1.70 GHz Intel Core i5 3rd Gen processor with 4 GB of DDR3 memory and a 64 GB SSD. Its fanless aluminium chassis carries an IP65-rated front panel and a 12.1″ TFT LED display with a high-temperature five-wire resistive touchscreen. Windows 10 Pro comes pre-installed, making the unit ready for embedded automation, kiosk or HMI deployments straight out of the box.

Sustained-load behaviour

Passive cooling relies on the aluminium housing to dissipate heat, so the system remains silent while the CPU manages thermal output under continuous industrial workloads. Operating temperature is rated 0–50 °C with the fitted SSD, dropping to 0–40 °C if a mechanical drive is added later. The watchdog timer offers 255 levels of hardware monitoring to recover from software stalls without manual intervention.

Interface practical limits

Video output is provided through one HDMI and one VGA port, each driving external displays at the panel’s native 1024 × 768 resolution. Four USB 2.0 ports and two COM ports handle legacy peripherals and serial equipment, while a single LAN jack covers wired networking. Internal expansion uses a full-size Mini PCIe slot with a SIM socket for 4G or Wi-Fi modules, and storage can be extended via the mSATA slot or a 2.5″ SATA bay.

Helstu kostir

  • IP65 front-panel protection for harsh environments
  • 1" resistive touch screen rated for 200 million touches
  • Fanless aluminium chassis runs silently from 0 °C to 50 °C
  • Intel Core i5 third-gen with 4 GB DDR3 and 64 GB SSD
  • VESA 75 mount plus HDMI, VGA, LAN and dual COM ports

Tæknilýsing

ModelA2-PA-121TPC-CE5B(I53)-4G64G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 3rd Gen
CPU Name1.70GHz
GPU/VGA TypeIntel HD Graphics
Memory Capacity4GB DDR3
SSD64GB
HDDNo
Screen Size12.1"
TouchscreenYes

Aðrar útgáfur af þessari vöru

5 í viðbót í sama vöruflokki

Sama fjölskylda, mismunandi minni, kælingu eða klukkuhraða — berðu saman áður en þú ákveður þig.

Spurningar um þessa vöru

How much heat and noise does the fanless aluminium housing produce during continuous operation?

The fanless aluminium chassis dissipates heat silently, with an operating range of 0 to 50 °C when the 64 GB SSD is installed, so it runs cool and quiet all day.

Which memory modules must I already have to reach the 8 GB maximum supported by the single SODIMM slot?

You need a DDR3L SODIMM rated at 1333 or 1600 MT/s; the system ships with 4 GB and accepts one module up to 8 GB total.

Can I keep using my existing VGA monitor and legacy COM devices with the HDMI, VGA and two COM ports on this unit?

Yes, the panel PC provides both HDMI and VGA video outputs plus two COM ports, so older displays and serial equipment connect directly.
