Silver 12.1 inch fanless industrial all-in-one with resistive touchscreen

partaker

Partaker A2 12.1" Industrial All-in-One PC Celeron J1900 8GB DDR3 256GB SSD 1TB HDD

SKU CH-ZYAE-5PVTT

A 12.1-inch industrial all-in-one PC with an IP65 front panel, fanless aluminium chassis and high-temperature five-wire resistive touchscreen, running a Celeron J1900 with 8GB DDR3L.

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeCeleron
  • CPU Name2.00GHz
  • GPU/VGA TypeIntel HD Graphics

GPU Intel HD Graphics

Memory 8GB DDR3

  • 4GB DDR3
  • 8GB DDR3

SSD 256GB

  • 64GB
  • 256GB
  • 512GB

HDD 1TB

Yfirstrikaðar útgáfur eru til, en ekki til hér.

  • IP65 front panel resists dust and water ingress
  • Fanless aluminium cooling runs silently in harsh environments
  • 200 million touch cycles ensure long-term reliability
  • Dual 256GB SSD plus 1TB HDD storage for OS speed and data capacity
  • Wide DC 100-240V input with auto power-on after outage

Industrial 12.1" Panel PC

The Partaker A2 is a compact all-in-one computer built for embedded industrial use. It combines a 12.1 inch TFT LED display with an Intel Celeron J1900 processor, 8GB DDR3L memory, 256GB mSATA SSD and a 1TB 2.5 inch SATA hard drive. The aluminium fanless chassis carries an IP65-rated front panel and a high-temperature five-wire resistive touchscreen. Windows 10 Pro is pre-installed for immediate deployment.

Suited for fixed automation and monitoring

This unit fits machine interfaces, kiosks and data-logging stations that need a sealed front face, legacy serial ports and dual-drive storage in a fanless enclosure. It is not for buyers who need a multi-touch projected capacitive screen, nor for applications that require higher processing throughput or discrete graphics performance. The 1024 x 768 resolution and resistive technology also rule out fine-detail visual work.

IP65 front-panel protection

The display bezel meets IP65 against dust and water jets, allowing the PC to be mounted directly into cabinet cut-outs of 301 x 229 mm or VESA 75 brackets. This sealing, combined with the 0 to 50 °C operating range on SSD and the fanless aluminium alloy cooling, decides whether the hardware survives the target environment.

Helstu kostir

  • IP65 front panel resists dust and water ingress
  • Fanless aluminium cooling runs silently in harsh environments
  • 200 million touch cycles ensure long-term reliability
  • Dual 256GB SSD plus 1TB HDD storage for OS speed and data capacity
  • Wide DC 100-240V input with auto power-on after outage

Tæknilýsing

ModelA2-PA-121TPC-CE5B(J19)-8G256G1TB
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeCeleron
CPU Name2.00GHz
GPU/VGA TypeIntel HD Graphics
Memory Capacity8GB DDR3
SSD256GB
HDD1TB
Screen Size12.1"
TouchscreenYes

Aðrar útgáfur af þessari vöru

5 í viðbót í sama vöruflokki

Sama fjölskylda, mismunandi minni, kælingu eða klukkuhraða — berðu saman áður en þú ákveður þig.

Spurningar um þessa vöru

Does the box include the power supply, power cord and mounting hardware, or must I buy them separately?

The packing list shows the Panel PC, power supply, power cord and embedded buckle kits are all included, so no separate purchase is needed for basic installation.

Should I choose the 256 GB mSATA SSD plus 1 TB 2.5" HDD, or is a single drive option available?

This model ships with both a 256 GB mSATA SSD and a 1 TB 2.5" SATA HDD already installed; no single-drive variant is offered in the listing.

What does the 2.42 GHz burst figure mean for daily workloads on the Celeron J1900?

The processor runs at a 2.0 GHz base and can reach 2.42 GHz for short bursts, giving responsive performance for typical industrial HMI, data logging and light edge-computing tasks.
