Black square axial case fan 60 by 60 by 25 mm with three wires

Zyvpee

Zyvpee AFB0612HH R00 60x25mm 12V 0.25A 3-pin 27.55 CFM case fan

SKU CH-3WWV-8T98G

A 60 mm ball-bearing axial fan moves 27.55 CFM at 12 V and 0.25 A through a three-wire connector

  • TypeCase Fan
  • CompatibilityCase
  • Bearing TypeBall
  • Power Connector3 Wires
  • ColorBlack
  • LEDNon-LED
  • High airflow of 27.55 CFM for effective case cooling
  • Ball bearing design ensures long operational life
  • 12 V 0.25 A power draw keeps energy use low
  • Compact 60 x 60 x 25 mm frame fits tight builds
  • Three-wire connector allows speed monitoring by motherboard

Compact 60 mm axial fan

The Zyvpee AFB0612HH R00 is a 60 mm square axial fan designed for tight case mounts or small-form-factor chassis where a 60 mm footprint is required. It targets builders who need directed airflow in confined spaces such as rack units, HTPC enclosures or GPU shroud replacements.

12 V three-wire power limit

The fan runs on a 12 V DC supply drawing 0.25 A through a three-wire connector that delivers power and a tachometer signal without PWM control. Speed is therefore fixed at the rated voltage; voltage regulation or a fan controller is needed for quieter operation.

27.55 CFM airflow capacity

At full speed the fan moves 27.55 CFM through its 25 mm thick frame, sufficient for spot-cooling voltage regulators, memory modules or a single low-TDP CPU. It will not satisfy high-wattage components or multi-GPU arrays that demand substantially greater static pressure or volume.

Helstu kostir

  • High airflow of 27.55 CFM for effective case cooling
  • Ball bearing design ensures long operational life
  • 12 V 0.25 A power draw keeps energy use low
  • Compact 60 x 60 x 25 mm frame fits tight builds
  • Three-wire connector allows speed monitoring by motherboard

Tæknilýsing

SeriesAFB0612HH
ModelAFB0612HH
TypeCase Fan
CompatibilityCase
Bearing TypeBall
Power Connector3 Wires
ColorBlack
LEDNon-LED
FeaturesDC square Cooler
Dimensions60*60*25mm

Spurningar um þessa vöru

How do I pick between the available versions of this AFB0612HH fan?

The listing shows a single configuration: 12 V, 0.25 A, 60×25 mm, 3-wire, 27.55 CFM, ball-bearing, non-LED black frame. No alternative capacities or speed grades are offered.

What does the 27.55 CFM rating mean once the fan is installed in a case?

It indicates the maximum free-air volume the axial fan can move at 12 V; actual airflow inside a chassis will be lower due to grilles, filters and component obstruction.

What does the 3-wire connector provide and what does it limit?

The three wires carry 12 V power, ground and a tachometer signal for speed reporting; they do not support PWM speed control, so the fan runs at full voltage unless the motherboard or controller reduces the DC level.
