Grey metal rectangular enclosure with front terminal block and status LEDs

ALTRONIX

ALTRONIX AL600ULXD industrial power supply 110/220 V AC 12/24 V DC 6 A

SKU CH-97XJ-P5HK5 MPN AL600ULXD

Converts 110/220 V AC to 12/24 V DC at 6 A continuous for industrial installations

  • Engine BrandAltronix
  • Converts 110 V or 220 V AC input for global installations
  • Delivers 12 V DC or 24 V DC output to match equipment needs
  • Supplies 6 A continuous current for reliable operation
  • Lifetime limited warranty backs long-term reliability
  • Compact 15.5 x 12 x 4.5 in enclosure fits tight spaces

Industrial dual-voltage power supply

The ALTRONIX AL600ULXD converts 110 V AC or 220 V AC input into selectable 12 V DC or 24 V DC output at up to 6 A continuous current. It is built for fixed industrial and security installations that need a single unit to handle both mains standards. The proprietary design delivers non-power-limited output from a wall-mounted enclosure.

Installers needing one supply for 12 V

Technicians who must power mixed-voltage access-control, CCTV or fire-alarm devices from a single 110 V AC or 230 V AC service will benefit. Sites that require power-limited outputs for Class 2 wiring or need higher than 2.5 A per voltage rail should look elsewhere.

2.5 A per voltage rail limit

Although the unit supplies 6 A total, each selectable output is rated at 2.5 A maximum at 12 V DC or 24 V DC. This per-rail ceiling determines whether the supply can drive the connected load without tripping.

Ciri-ciri utama

  • Converts 110 V or 220 V AC input for global installations
  • Delivers 12 V DC or 24 V DC output to match equipment needs
  • Supplies 6 A continuous current for reliable operation
  • Lifetime limited warranty backs long-term reliability
  • Compact 15.5 x 12 x 4.5 in enclosure fits tight spaces

Spesifikasi

Engine BrandAltronix

Soalan tentang produk ini

What is the continuous current limit at 12 V DC before the supply trips?

The unit delivers a continuous 6 A at 12 V DC; the output is non-power limited so the 6 A rating is the sustained limit.

How hot or loud does the AL600ULXD get when running 24/7 at full load?

The 13.90 lb steel enclosure uses convection cooling with no fan, so it runs silently; surface temperature will rise but stays within the industrial rating.

Which input voltage selector must be set on site for 230 V AC mains?

The supply accepts 115 V AC or 230 V AC 60 Hz; set the internal jumper to the 230 V position before applying power.
