Green circuit board with silver PCI-Express connector and black heatsink

DELL

DELL PERC H730 12Gbps SAS SATA PCI-Express 3.0 Raid Controller Card 5P6JK

SKU CH-BJ40-R4ASY

A 12 Gbps SAS and SATA RAID controller with 1 GB cache, PCIe 3.0 x8 connectivity and support for RAID 0, 1, 5, 10 and passthrough modes

  • Speed12Gbps
  • InterfacePCI-Express
  • Temperature0°C ~ 55°C
  • Class10/100M
  • 12Gbps SAS/SATA throughput accelerates storage arrays
  • PCI Express 3.0 x8 interface delivers high-bandwidth connectivity
  • 1GB NV cache boosts RAID write performance
  • Supports RAID and passthrough modes for flexible deployment
  • Operates reliably from 0°C to 55°C

Dell PERC H730 RAID Controller

The Dell PERC H730 is a 12Gbps SAS/SATA RAID controller card that installs in a PCI-Express 3.0 x8 slot. It provides essential RAID levels and non-RAID passthrough modes for connecting hard drives and solid-state drives. The card includes 1GB of NV cache to accelerate write performance. It is suited for servers needing direct-attached storage management.

Sustained operation at 12Gbps within 0°C to 55°C

The controller maintains its 12Gbps link speed across the rated 0°C to 55°C operating temperature range. The 1GB NV cache absorbs write bursts during heavy I/O, helping sustain throughput without throttling. Class 10/100M management traffic runs independently of the data path. Buyers who need cache protection beyond the onboard NV cache should verify external backup options.

PCI-Express 3.0 x8 installation and cabling

The half-height card seats in any PCI-Express 3.0 x8 or wider slot and draws power from the slot itself. Internal SAS/SATA connectors accept standard breakout cables for drive backplanes or direct drive attachment. No driver media is included; firmware and drivers must be downloaded from the vendor support site. Installers who lack compatible cables or a free x8 slot will need additional parts.

Ciri-ciri utama

  • 12Gbps SAS/SATA throughput accelerates storage arrays
  • PCI Express 3.0 x8 interface delivers high-bandwidth connectivity
  • 1GB NV cache boosts RAID write performance
  • Supports RAID and passthrough modes for flexible deployment
  • Operates reliably from 0°C to 55°C

Spesifikasi

BrandDell
Part Number5P6JK
Speed12Gbps
InterfacePCI-Express
Temperature0°C ~ 55°C
Class10/100M

Soalan tentang produk ini

How much power and heat does the PERC H730 12Gbps controller produce when running continuously?

The card operates within a 0°C to 55°C range, indicating standard server thermal design for all-day workloads.

Which PCI-Express slot and version does the 5P6JK need on the motherboard?

It requires a PCI-Express 3.0 x8 slot for full 12Gbps SAS and SATA bandwidth.

Will the PERC H730 work with older 6Gbps SAS or 3Gbps SATA drives I already own?

Yes, the 12Gbps controller is backward compatible with slower SAS and SATA drives for tiered storage.
