Quad-port Intel network card, black PCB, four RJ45 ports, PCIe x8 bracket

Intel

Intel X710T4LBLK quad-port 10GbE network card

SKU CH-137H-PD6RY MPN X710T4LBLK

Quad-port 10GbE adapter with multi-speed RJ45 links, PCIe 3.0 x8 interface and virtualisation offloads for efficient server networking

  • SpeedData rate per port: 10GbE/5GbE/2.5GbE/1GbE/100Mb
  • Connectors4 x RJ45
  • InterfacePCI-Express 3.0 x8
  • TemperatureOperating Temperature: 0 °C to 55 °C (32 °F to 131 °F) Stora
  • HumidityStorage Humidity Maximum: 90% non-condensing relative humidi
  • Dimensions167 mm x 69 mm

Model X710T4LBLK

  • X710DA2
  • X710DA2BLK
  • X710DA4FHBLK
  • X710T2L
  • X710T2LBLK
  • X710T4L
  • X710T4LBLK

Versi yang dicoret wujud, tetapi tidak tersedia di sini.

Connector RJ45

  • RJ45
  • SFP+ (DAC and Fiber Optic)

Versi yang dicoret wujud, tetapi tidak tersedia di sini.

Ports 4 ports

  • 2 ports
  • 4 ports

Versi yang dicoret wujud, tetapi tidak tersedia di sini.

  • Quad-port 10/5/2.5/1GbE RJ45 connectivity for flexible server uplinks
  • PCIe 3.0 x8 interface delivers high-throughput data paths
  • Energy Efficient Ethernet IEEE 802.3az cuts power during low traffic
  • Hardware Flow Director and DDP offloads accelerate NFV and cloud workloads
  • DPDK optimisation plus VxLAN, GENEVE, NVGRE, MPLS offloads boost virtualised performance

Quad-port 10GbE adapter for dense server builds

The Intel X710T4LBLK delivers four RJ45 ports, each auto-negotiating 10GbE down to 100Mb. It targets administrators who need high port density in a single PCIe 3.0 x8 slot for virtualization hosts, network appliances or NFV platforms.

Multi-speed headroom with EEE power savings

Each port steps between 10GbE, 5GbE, 2.5GbE, 1GbE and 100Mb, so existing cabling remains usable while new links run at line rate. Energy Efficient Ethernet idles unused lanes, keeping draw low during quiet periods. Operating range stops at 55 °C, so sustained load in hot aisles needs directed airflow.

Low-profile x8 card with virtualization offloads

The 167 mm by 69 mm bracket fits standard low-profile bays and requires an x8 electrical link; an x4 slot halves bandwidth. Hardware offloads for VxLAN, GENEVE, NVGRE, MPLS and NSH plus Flow Director and DDP profiles accelerate tenant traffic. DPDK optimisation lets user-space stacks process small packets at line rate. Buyers needing fibre media or more than four ports must add separate adapters.

Ciri-ciri utama

  • Quad-port 10/5/2.5/1GbE RJ45 connectivity for flexible server uplinks
  • PCIe 3.0 x8 interface delivers high-throughput data paths
  • Energy Efficient Ethernet IEEE 802.3az cuts power during low traffic
  • Hardware Flow Director and DDP offloads accelerate NFV and cloud workloads
  • DPDK optimisation plus VxLAN, GENEVE, NVGRE, MPLS offloads boost virtualised performance

Spesifikasi

BrandIntel
ModelX710-T4LBLK
Part NumberX710T4LBLK
SpeedData rate per port: 10GbE/5GbE/2.5GbE/1GbE/100Mb
Connectors4 x RJ45
InterfacePCI-Express 3.0 x8
TemperatureOperating Temperature: 0 °C to 55 °C (32 °F to 131 °F)
Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
HumidityStorage Humidity Maximum: 90% non-condensing relative humidity at 35 °C
Dimensions167 mm x 69 mm
Berat penghantaran0.23 kg
Dimensi bungkusan203 × 140 × 25 mm

Versi lain model ini

2 lagi dalam julat yang sama

Keluarga yang sama, memori, penyejuk atau kelajuan jam yang berbeza — bandingkan sebelum membuat keputusan.

Soalan tentang produk ini

Will the 10GbE/5GbE/2.5GbE/1GbE/100Mb ports autonegotiate with my existing 1GbE switch and Cat5e cabling?

Yes, each RJ45 port supports multi-speed operation and will autonegotiate down to 1GbE or 100Mb over Cat5e, so your current switch and cables work without changes.

How can I verify the adapter is running at 10GbE after installation?

Check the link speed reported by the OS or the adapter LEDs; a 10GbE link shows 10Gbps on each active port when connected to a 10GBASE-T switch with Cat6a or better cabling.

Does the box include low-profile brackets or SFP+ modules for the four RJ45 ports?

The adapter ships with a full-height bracket only; low-profile brackets and SFP+ modules are not included and must be purchased separately if required.
