Green circuit board with silver ports and black chips

Khadas

Khadas Edge2 RK3588S 16GB 64GB development board

SKU CH-FVA4-BB805

Compact development board with an 8-core Rockchip RK3588S SoC, 16 GB RAM, 64 GB storage, 6 TOPS NPU and Wi-Fi 6 for 8K video and multi-display projects

Name Pro kit

  • 8-core 64-bit CPU at 2.25 GHz delivers fast edge computing
  • Mali-G610 MP4 GPU up to 1 GHz handles 8K video decode and encode
  • 6 TOPS NPU accelerates on-device AI inference workloads
  • Wi-Fi 6 2T2R module provides stable high-speed wireless connectivity
  • Four display interfaces enable multi-screen development setups

Edge2 RK3588S 16GB 64GB development board

The Khadas Edge2 is a compact IoT edge device built around the Rockchip RK3588S system-on-chip. It delivers an 8-core 64-bit CPU with four Cortex-A76 cores at 2.25 GHz and four Cortex-A55 cores at 1.8 GHz, a Mali-G610 MP4 GPU at 1 GHz and a 6 TOPS neural processing unit. The board ships with 16 GB of RAM and 64 GB of onboard storage.

Makers, AI prototypists and media appliance builders

Developers who need hardware-accelerated 8K video decode at 60 fps, 8K encode at 30 fps or up to 32 simultaneous 1080p decode streams will find the media engine suitable. The 6 TOPS NPU supports on-device inference workloads. Buyers who require a bundled power adapter or USB-C cable must source those separately.

6 TOPS NPU and 8K media pipeline

The integrated 6 TOPS neural processing unit combined with 8K@60fps H.265/VP9 decoding and 8K@30fps H.265/H.264 encoding is the specification that determines whether this board fits a computer-vision or high-resolution media project.

Ciri-ciri utama

  • 8-core 64-bit CPU at 2.25 GHz delivers fast edge computing
  • Mali-G610 MP4 GPU up to 1 GHz handles 8K video decode and encode
  • 6 TOPS NPU accelerates on-device AI inference workloads
  • Wi-Fi 6 2T2R module provides stable high-speed wireless connectivity
  • Four display interfaces enable multi-screen development setups

Spesifikasi

Belum ada spesifikasi diterbitkan untuk produk ini.

Versi lain model ini

1 lagi dalam julat yang sama

Keluarga yang sama, memori, penyejuk atau kelajuan jam yang berbeza — bandingkan sebelum membuat keputusan.

Soalan tentang produk ini

Do I need to buy a separate power adapter and USB-C cable to run the Edge2 board?

Yes, the kit includes only the board, a user manual and a warranty card; a power adapter and USB-C cable are sold separately.

Can I connect four independent screens to the HDMI, USB-C and two DSI ports at the same time?

The hardware provides one HDMI, one USB-C and two DSI interfaces, but the actual number of independent displays depends on the operating system.

How can I confirm the 6 TOPS NPU is active after setup?

Run an AI workload or benchmark that reports NPU utilisation; the SoC integrates a 6 TOPS NPU that will show load when the software uses it.
