Compact silver servo with three side channels, 54.38 x 20.14 x 45.5 mm, 64g

LORDWORLD

LORDWORLD HTS-35H High Voltage Bus Servo 35KG Torque Three Channels Feedback

SKU CH-JQ53-H4T3A

High-voltage bus servo delivers 35 kg.cm torque at 7.4 V with 240° powered and 360° free rotation plus position, temperature and voltage feedback

  • High torque of 35kg.cm at 7.4V for demanding robot joints
  • Triple feedback of position, temperature and voltage protects against burnout
  • Three wiring channels on top, left and right simplify cable routing
  • Compact 54.38 x 20.14 x 45.5mm body weighs only 64g
  • Modifiable default ID 1 allows flexible bus addressing

High-Torque Bus Servo for Robot Joints

The LORDWORLD HTS-35H delivers up to 35 kg.cm of torque at 7.4 V, making it suitable for robot joint actuation. It offers 240 degrees of rotation under power and freewheels through 360 degrees when unpowered. Position, temperature and voltage feedback help prevent overload damage.

Simple Three-Channel Wiring and ID Setup

Three connection channels on the top, left and right sides keep cable routing tidy. The default servo ID is 1 and can be reprogrammed to fit a bus network. No special tools are required beyond standard servo connectors and a configuration utility.

Check Voltage Supply and Physical Clearance

Verify that your power source can provide a stable 7.4 V to reach the rated torque. Confirm the 54.38 x 20.14 x 45.5 mm footprint and 64 g mass fit your mechanical design. Ensure your controller supports the feedback protocol for temperature and voltage monitoring.

Ciri-ciri utama

  • High torque of 35kg.cm at 7.4V for demanding robot joints
  • Triple feedback of position, temperature and voltage protects against burnout
  • Three wiring channels on top, left and right simplify cable routing
  • Compact 54.38 x 20.14 x 45.5mm body weighs only 64g
  • Modifiable default ID 1 allows flexible bus addressing

Spesifikasi

BrandLORDWORLD

Soalan tentang produk ini

How can I confirm the HTS-35H is operating correctly after installation?

Verify the servo moves through its 240 degree powered range and 360 degree free rotation, then monitor the position, temperature and voltage feedback channels for stable readings under load.

What comes with the HTS-35H and what must I source separately?

The package includes the 64 g servo unit with three integrated wiring channels on the top, left and right sides; you will need to supply a 7.4 V power source and a compatible bus controller.

Which HTS-35H version should I choose for a high-torque robot joint?

This single model delivers up to 35 kg·cm at 7.4 V with 240 degree rotation and full feedback, making it the appropriate choice for demanding joint applications.
