Green rectangular development board with 40-pin GPIO header and multiple connectors

LORDWORLD

LORDWORLD Mini Base Board (A) for Raspberry Pi Compute Module 4

SKU CH-ZX72-EAQJ4

Carrier board for Raspberry Pi Compute Module 4 with 40-pin GPIO, HDMI, USB, Gigabit Ethernet, CSI, DSI, fan header, microSD slot and M.2 slot

  • Evaluates Raspberry Pi CM4 with standard socket and color-coded 40-pin GPIO
  • Integrates into end products using CM4 Lite or eMMC modules
  • Compact board includes CSI, DSI, fan, HDMI, USB, Gigabit Ethernet RJ45
  • Micro SD card slot and M.2 slot provide flexible storage options
  • Complete I/O set in a small form factor for embedded development

Compact carrier for Compute Module 4

The LORDWORLD Mini Base Board (A) provides a standard CM4 socket and colour-coded 40-pin GPIO header. It accepts both Lite and eMMC variants of the Compute Module 4. The board targets developers evaluating the module or integrating it into finished IoT edge devices. Its small footprint keeps the full feature set accessible in tight enclosures.

Onboard I/O replaces loose breakout cables

The carrier consolidates CSI, DSI, fan, HDMI, USB, Gigabit Ethernet RJ45, micro SD slot and an M.2 connector onto one PCB. This removes the need for separate adapter boards during prototyping or pilot production. The jump is worth it when a project moves from breadboard to a rugged, repeatable form factor.

Handles dual camera, display and high-speed storage

The CSI and DSI interfaces support camera and display modules simultaneously. The M.2 slot adds fast solid-state storage while the micro SD slot remains available for boot media. Gigabit Ethernet and USB give wired network and peripheral headroom. The board runs out when an application needs more than one M.2 device or additional PCIe lanes.

Ciri-ciri utama

  • Evaluates Raspberry Pi CM4 with standard socket and color-coded 40-pin GPIO
  • Integrates into end products using CM4 Lite or eMMC modules
  • Compact board includes CSI, DSI, fan, HDMI, USB, Gigabit Ethernet RJ45
  • Micro SD card slot and M.2 slot provide flexible storage options
  • Complete I/O set in a small form factor for embedded development

Spesifikasi

BrandLORDWORLD

Soalan tentang produk ini

Does the board use the standard CM4 socket and 40-pin GPIO header?

Yes, it connects with a standard CM4 socket and a color-coded 40-pin GPIO header.

How is the Compute Module 4 fitted to the base board?

The module plugs into the standard CM4 socket; the step often missed is pressing evenly until the connectors fully seat.

What storage expansion does the onboard M.2 slot provide?

The M.2 slot accepts compatible modules for additional storage beyond the micro SD card slot.
