Rectangular black metal UPS with LCD screen and six outlets on rear panel

MINUTEMAN

MINUTEMAN EC1500RT2U 1500VA 1350W 2U Rack/Tower UPS

SKU CH-9X31-RZ53V MPN EC1500RT2U

Double-conversion UPS delivers 1500VA/1350W with 5-minute full-load runtime and six NEMA 5-15R outlets in a 2U rack/tower chassis

  • International Version120V
  • Input Voltage Range0-160VAC
  • Input Frequency50/60Hz +/-6Hz Auto-sensing
  • VA Rating1500VA
  • Watts1350W
  • Output Voltage120V

Model EC1500RT2U

  • EC1500RT2U
  • EC1000LCD
  • EC1000LCD-NC
  • EC1000RTXL2U
  • EC1000RTXL2UNC
  • EC1500LCD
  • EC1500LCD-NC
  • EC1500RT2UNC
  • EC1500RTXL2U
  • EC1500RTXL2UNC
  • EC2000LCD
  • EC2000LCD-NC
Lihat 7 konfigurasi lagi
  • EC2000RTXL2U
  • EC2000RTXL2UNC
  • EC3000LCD
  • EC3000LCD-NC
  • EC3000RT2U
  • EC3000RT2UNC
  • EC3000RTXL2UNC

Versi yang dicoret wujud, tetapi tidak tersedia di sini.

  • True on-line double-conversion topology protects critical equipment from all power disturbances
  • 9 output power factor delivers 1350 W real power from 1500 VA rating
  • Hot-swappable, tool-less battery replacement keeps the UPS running during maintenance
  • Independent battery bypass maintains surge protection even with dead or removed batteries
  • Selectable high-efficiency economy mode reduces operating cost and heat output

Product Identity

The Minuteman Encompass EC1500RT2U is a 1500VA, 1350W online double-conversion UPS in a 2U rack/tower chassis. It delivers a 0.9 output power factor and pure sine-wave power to six NEMA 5-15R receptacles from a 120V input.

Fit and Exclusions

It suits small server racks, network closets, or desktop towers needing continuous voltage regulation and battery backup with hot-swappable batteries. Buyers who need longer runtime at full load than five minutes or who operate on non-120V mains should look at other models.

Deciding Specification

The unit provides five minutes of battery runtime at the full 1350W load and fifteen minutes at half load, which determines whether it can bridge your typical outage duration.

Ciri-ciri utama

  • True on-line double-conversion topology protects critical equipment from all power disturbances
  • 9 output power factor delivers 1350 W real power from 1500 VA rating
  • Hot-swappable, tool-less battery replacement keeps the UPS running during maintenance
  • Independent battery bypass maintains surge protection even with dead or removed batteries
  • Selectable high-efficiency economy mode reduces operating cost and heat output

Spesifikasi

BrandMINUTEMAN
SeriesENCOMPASS
ModelEC1500RT2U
International Version120V
Input Voltage Range0-160VAC
Input Frequency50/60Hz +/-6Hz Auto-sensing
VA Rating1500VA
Watts1350W
Output Voltage120V
Output Frequency50/60Hz ±0.2Hz unless synchronized to line
Outlets6
Outlet Type(6) NEMA 5-15R
Battery TypeSealed Lead Acid
Battery Run TimeHalf Load: 15 min
Full Load: 5 min
Battery Recharge Time8 hours to 90% from total discharge
Battery ReplaceableBM0070
Interface PortDB-9, USB, RJ-45
ApprovalscTUVus (Conforms to UL1778 5th Edition & CSA 22.2 no. 107.3-14 / R: 2014), FCC Class A, CE certified, RoHS2 (EU Directive 2011/65/EU)
Surge Energy Rating254 Joules
TemperatureOperating (max)/Storage Temperature: +32 to +104°F (0 to 40°C) / +14 to +122°F (-10 to +50°C)
Humidity10% to 90% non-condensing
Dimensions19.2" x 3.5" x 18.9"
Weight44.1 lbs.
Berat penghantaran22.68 kg
Dimensi bungkusan654 × 546 × 216 mm

Soalan tentang produk ini

How can I confirm the UPS is regulating voltage correctly after installation?

The LCD display shows real-time input and output voltage; verify the output reads 120 V while the input may vary between 0 and 160 VAC.

What ships with the unit and what must I purchase separately?

The package includes the Encompass EC1500RT2U UPS only; rack-mount rails, network management cards and replacement battery cartridge BM0070 are sold separately.

Which capacity should I choose for a 1350 W load?

This model delivers 1500 VA / 1350 W at 0.9 power factor — select it when your equipment draws up to 1350 watts.
