Compact black aluminium mini PC with cooling fan, 170 by 140 by 58 mm

partaker

partaker N7 barebone mini PC i3-1215U 8GB 256GB

SKU CH-5FV1-H2WME

Fan-cooled barebone with a 12th-gen Core i3, three 2.5 GbE ports, triple 4K HDMI and dual COM for industrial IoT gateways

  • ColorBlack
  • CPU TypeIntel Core i3 12th Gen

CPU Type Intel Core i3-1215U

Group 8GB / 256GB SSD

  • Fanless-style cooling in a compact aluminium chassis
  • Triple 2.5 GbE Intel i225-V ports for high-speed networking
  • Three HDMI outputs drive three 4K displays simultaneously
  • DDR5 4800 SODIMM slot supports up to 32 GB memory
  • Industrial temperature range from -20 °C to +50 °C with SSD

Industrial mini PC with triple 2.5G LAN

The partaker N7 is a fan-cooled barebone built around an Intel Core i3 1215U processor with six cores and eight threads reaching 4.4 GHz turbo. It targets system integrators deploying edge gateways, industrial automation controllers, or machine-vision nodes that need multiple wired network links in a compact aluminium chassis.

Upgrade from single-LAN fanless boxes

Replacing older appliances that offer only one gigabit port and passive cooling, this unit adds three Intel i225-V 2.5G LAN interfaces and active airflow for sustained loads. The jump is worth it when deterministic networking, PXE boot, or watchdog reliability are required in 0 °C to 40 °C commercial or -20 °C to 50 °C industrial temperature ranges.

8 GB DDR5 and 256 GB NVMe headroom

The single DDR5 4800 SODIMM slot accepts up to 32 GB, while the M.2 2280 M-key slot and a 2.5-inch bay provide layered storage expansion. The pre-installed 8 GB memory and 256 GB NVMe drive handle typical IoT gateway workloads; memory-intensive analytics or local logging will need the additional RAM and storage capacity the slots allow.

Ciri-ciri utama

  • Fanless-style cooling in a compact aluminium chassis
  • Triple 2.5 GbE Intel i225-V ports for high-speed networking
  • Three HDMI outputs drive three 4K displays simultaneously
  • DDR5 4800 SODIMM slot supports up to 32 GB memory
  • Industrial temperature range from -20 °C to +50 °C with SSD

Spesifikasi

ColorBlack
CPU TypeIntel Core i3 12th Gen

Versi lain model ini

5 lagi dalam julat yang sama

Keluarga yang sama, memori, penyejuk atau kelajuan jam yang berbeza — bandingkan sebelum membuat keputusan.

Soalan tentang produk ini

What are the exact dimensions and weight of the N7 so I can confirm it fits my VESA mount?

The unit measures 170 x 140 x 58 mm and weighs 2.5 kg. It includes a VESA mount for attachment to compatible brackets.

Which RAM slot and storage bays do I populate first during assembly?

Install a single DDR5 4800 SODIMM module into the sole memory slot. Add an NVME drive to the M.2 2280 M-Key slot and a 2.5-inch drive into the internal bay.

How often should I clean the internal fan to maintain airflow in dusty environments?

Inspect the fan and vents every 3 to 6 months. Use compressed air to remove dust buildup and ensure the surface airflow cooling remains effective.
