Black rectangular wired video doorbell with chime, 133 by 48 by 23 mm, 180 degree diagonal view

Reolink

Reolink WiFi Wired Video Doorbell with Chime 5MP 180°

SKU CH-T8GH-E3D8G

A 5-megapixel wired video doorbell with 180-degree diagonal view, dual-band Wi-Fi, person and package detection, and an included plug-in chime

  • ProtocolHTTPS, IPv4, UPNP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS,
  • TypeSecurity & Motion
  • ColorBlack
  • App-EnabledYes
  • Amazon Alexa CompatibilityYes
  • Google Assistant CompatibilityYes
  • 5MP ultra HD resolution captures detailed visitor footage at 2560×1920
  • 180° diagonal field of view with 4:3 aspect ratio covers wide entryway area
  • Dual-band 2.4/5GHz WiFi provides stable wireless connectivity for reliable alerts
  • Included plug-in chime with 10 selectable tunes sounds throughout the home
  • Two-way audio with preset voice messages lets you respond remotely anytime

Wired 5MP Doorbell with Chime

The Reolink WiFi Wired Video Doorbell captures 5MP video at 2560×1920 resolution and includes a plug-in chime for indoor alerts. It suits homeowners who want a hard-wired doorbell with dual-band WiFi connectivity and local recording options. Buyers who need a battery-only installation cannot use this model.

Black Housing with Wedge Mount

The unit measures 133mm by 48mm by 23mm and weighs 96g, featuring a 1/2.7" CMOS sensor behind an f=2.26mm F=2.0 lens with IR cut. A 15° wedge and mounting plate allow angle adjustment, while the 1.5m power adapter and extension cables support flexible wiring. The chime offers ten selectable tunes with adjustable volume.

180° Diagonal View and H.264

The camera provides a 180° diagonal field of view with 135° horizontal and 100° vertical coverage using a 4:3 aspect ratio. Video is encoded in H.264 at 20FPS and supports motion, scheduled and 24/7 recording modes. ONVIF and RTSP compatibility enable integration with compatible NVRs or home-assistant platforms.

Ciri-ciri utama

  • 5MP ultra HD resolution captures detailed visitor footage at 2560×1920
  • 180° diagonal field of view with 4:3 aspect ratio covers wide entryway area
  • Dual-band 2.4/5GHz WiFi provides stable wireless connectivity for reliable alerts
  • Included plug-in chime with 10 selectable tunes sounds throughout the home
  • Two-way audio with preset voice messages lets you respond remotely anytime

Spesifikasi

BrandReolink
ModelWiFi Wired Doorbell
ProtocolHTTPS, IPv4, UPNP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
TypeSecurity & Motion
ColorBlack
App-EnabledYes
Amazon Alexa CompatibilityYes
Google Assistant CompatibilityYes
ConnectivityWired
BatteryBattery not Included
SpecificationsImage Sensor
1/2.7" CMOS Sensor
Video Resolution
Default: 2560×1920 (5 megapixels) @20FPS
Lens
f=2.26mm F=2.0, with IR cut
Videoformat
H.264
Field of View
Horizontal: 135°
Vertical: 100°
Diagonal: 180°
Pre-Motion Recording
YES
Audio
Two-way audio, noise reduction, echo suppression
Quick Replies
YES
FeaturesSmart Alarm
Motion detection/person detection/package detection; visitor notification
Recording Modes
Motion recording (default); 24/7 recording; scheduled recording
Dimensions133mm (H) ×48mm (W) ×23mm (T)
Weight96g
Package ContentsDoorbell Camera ×1
Reolink Chime ×1
Mounting Plate ×1
Wedge ×1
1.5m Power Adapter ×1
4.5m & 0.1m Power Extension Cables ×1
Jumper Cables ×1
Extension Cable ×1
1m Network Cable ×1

Soalan tentang produk ini

Does the 2.4 GHz and 5 GHz Wi-Fi support handle 5 MP video at 20 FPS without buffering?

The doorbell streams 2560×1920 at 20 FPS over either 2.4 GHz or 5 GHz Wi-Fi; 5 GHz gives a more stable connection for the 5 MP feed.

Will the 133 mm × 48 mm × 23 mm unit with the 15° wedge fit my existing doorbell wiring and frame?

The camera weighs 96 g and measures 133 mm high by 48 mm wide by 23 mm deep; the included 15° wedge lets you angle it on standard door frames.

How do I wire the 1.5 m power adapter and chime so the doorbell records before motion triggers?

Connect the 1.5 m adapter to existing doorbell wires using the jumper cables, plug the chime into any indoor socket, then enable pre-motion recording in the app.
