Square pale grey silicone thermal pad 100 by 100 by 0.5 mm soft clay like texture

Thermal Grizzly

Thermal Grizzly Minus Pad Extreme 100x100x0.5mm thermal pad

SKU CH-VT6N-1CSY4

Silicone thermal pad sized 100 × 100 × 0.5 mm with 260 % higher conductivity than Minus Pad 8 for VRMs and memory ICs

  • Long Term Operating Temperature-100 °C / +200 °C
  • FeaturesHardness Shore 00 - 65 Thickness 0,5–3,0 mm Typical thicknes

Option 100 x 100 x 0.5 mm

  • Electrically insulating at 8 kV/mm per ASTM D149
  • 260 % higher conductivity than Minus Pad 8
  • Silicone clay consistency moulds perfectly under compression
  • Shore 00-65 hardness with V-0 flammability rating
  • Stable from -100 °C to +200 °C long term

Silicone thermal pad 100×100×0,5 mm

The Thermal Grizzly Minus Pad Extreme is a silicone-based thermal interface pad measuring 100 mm by 100 mm with a 0,5 mm thickness. Its modelling-clay consistency allows it to conform perfectly to uneven surfaces and achieve maximum compression. The pad is electrically insulating at 8 kV/mm per ASTM D149 and rated for continuous operation from -100 °C to +200 °C. It is designed for one-time installation on components such as voltage regulators and memory ICs.

Builders needing high-compression gap filling

This pad suits builders who need a soft, highly compressible interface that fills variable gaps without bleeding or pump-out over time. The Shore 00-65 hardness and 260 % conductivity improvement over the Minus Pad 8 make it effective for demanding thermal loads. Buyers who require a reusable pad or a pre-cut shape for a specific GPU or CPU block should look elsewhere, as the material is intended for single use and comes only as a square sheet.

0,5 mm thickness with ±0,1 mm tolerance

The critical specification is the 0,5 mm nominal thickness and its ±0,1 mm manufacturing tolerance. This range determines whether the pad will bridge the exact stack height between your component and heatsink without excessive stress or insufficient contact. Verify the required gap before purchasing, as the pad cannot be stretched or layered reliably.

Ciri-ciri utama

  • Electrically insulating at 8 kV/mm per ASTM D149
  • 260 % higher conductivity than Minus Pad 8
  • Silicone clay consistency moulds perfectly under compression
  • Shore 00-65 hardness with V-0 flammability rating
  • Stable from -100 °C to +200 °C long term

Spesifikasi

BrandThermal Grizzly
SeriesMinus Pad Extreme
Long Term Operating Temperature-100 °C / +200 °C
FeaturesHardness Shore 00 - 65
Thickness 0,5–3,0 mm
Typical thickness tolerance ± 0,1 mm
Flammability V-0
Electically insulating Ja (8 KV/mm ASTM D149)
Density 3.38 g/cm³
Temperature Range -100 °C / +200 °C

Versi lain model ini

1 lagi dalam julat yang sama

Keluarga yang sama, memori, penyejuk atau kelajuan jam yang berbeza — bandingkan sebelum membuat keputusan.

Soalan tentang produk ini

How do I install the 0.5 mm Minus Pad Extreme without tearing it, and what step do people get wrong?

Cut the 100x100 mm sheet to size, peel the protective film, place the pad on the component, then mount the heatsink with even pressure; the common mistake is reusing the pad after the first compression, which the maker says is one-time only.

Will the Minus Pad Extreme need replacement, and what signals that it is time?

The silicone pad is rated for long-term stability from -100 °C to +200 °C with no bleeding, so it does not dry out; replace it only if the heatsink is removed or if physical damage appears during a later inspection.

What thermal limit appears first when the pad runs under sustained load?

The pad itself stays stable up to +200 °C, so the first limit is usually the component’s own maximum junction temperature or the heatsink’s dissipation capacity, not the pad’s 8 kV/mm insulation or V-0 flammability rating.
