Silver 2U rack server with sixteen 2.5-inch drive bays and front bezel

DELL

DELL PowerEdge R760 2U rack server 2× Xeon Gold 5415+ 2.9GHz 512GB DDR5 H965i 4× 960GB SSD

SKU CH-09FT-T4XS3

A 2U rack server with dual 8-core Xeon Gold 5415+ CPUs, 512 GB DDR5 memory, H965i RAID controller and four 960 GB SATA SSDs

TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.9GHz (4.1GHz Turbo)
CPU SocketLGA 4677

Dual Xeon Gold 5415+ processors with 4.1GHz turbo speed
512GB DDR5-4800 ECC registered memory across 16 modules
PERC H965i RAID controller with 8GB NV cache supporting RAID 0/1/5/6/10/50/60
Four 960GB SATA enterprise SSDs in 2.5-inch hot-swap bays
iDRAC9 Datacenter remote management with quad-port 1GbE OCP 3.0 networking

21 666,99 щ.д.

0.27667169 BTC по днешния курс

В наличност · изпраща се днес

На касата курсът се заключва за 30 минути.

Доставка до Съединени щати ориентировъчно

UPS Worldwide Expedited 3–6 работни дни Безплатно
DHL Express Worldwide 2–3 работни дни 74,90 щ.д.

Вносните мита се начисляват от Вашата държава при пристигане.

Доставка на друг адрес

2U rack server with dual Xeon Gold 5415+

The Dell PowerEdge R760 is a 2U rack server equipped with two Intel Xeon Gold 5415+ processors running at 2.9 GHz base and 4.1 GHz turbo. It ships with 512 GB of DDR5-4800 ECC registered memory across 16 modules. The system targets virtualization, AI inference, databases and software-defined storage workloads.

Redundant 1400 W platinum power supplies

Dual 1400 watt platinum-efficiency power supplies provide hot-swap redundancy for continuous operation. Sixteen 2.5-inch hot-swap drive bays support SAS, SATA and NVMe devices. The platform uses DDR5 memory and PCI Express Gen5 expansion slots for high-throughput I/O.

PERC H965i controller with 8 GB NV cache

The Dell PERC H965i front RAID controller supports RAID 0, 1, 5, 6, 10, 50 and 60 with 8 GB of non-volatile cache. Four 960 GB SATA SSDs are installed. A Broadcom 5720 quad-port 1 GbE OCP 3.0 card and iDRAC9 Datacenter handle networking and remote management. Ready rails and a front bezel are included.

Акценти

Dual Xeon Gold 5415+ processors with 4.1GHz turbo speed
512GB DDR5-4800 ECC registered memory across 16 modules
PERC H965i RAID controller with 8GB NV cache supporting RAID 0/1/5/6/10/50/60
Four 960GB SATA enterprise SSDs in 2.5-inch hot-swap bays
iDRAC9 Datacenter remote management with quad-port 1GbE OCP 3.0 networking

Спецификации

Brand	DELL
Series	PowerEdge
Model	R760
Type	Rack
Rack Height	2U
Redundant Hot-swap Power	Yes
CPU Type	Intel Xeon
CPU Speed	2.9GHz (4.1GHz Turbo)
CPU Socket	LGA 4677
Number of CPU Cores	8 Core-Processors
CPU Features	Gold 5415+
# of Processors Installed	2
MAX Processors	2
Installed Memory Size	512GB
Memory Type	DDR5
Max Memory Capacity	8TB
Number of Memory Slots	32
Hard Drive (Installed)	None
Storage Controller	Dell Perc H965i Controller
HDD Interface	SATA
SSD (Installed)	4 x 960GB SATA SSD
Raid Level	RAID 0/1/5/6/10/50/60
Ethernet Controller	Dell EMC Broadcom 5720 Quad Port 1GbE OCP 3.0 Network Card
Remote Management	iDRAC9 Datacenter
LAN Ports	4 x Ports
Management Port	RJ 45
Operating System	No

Въпроси за този артикул

How do I install the Dell PERC H965i RAID controller and what step is often missed?

Mount the H965i in its dedicated front slot, connect the 8 GB NV cache module, then use the UEFI RAID utility to create virtual disks before the OS sees any of the 960 GB SSDs.

What maintenance will the 512 GB DDR5-4800 memory need over time?

The sixteen 32 GB ECC registered DIMMs are sealed modules; only firmware updates via iDRAC9 are required — no user-serviceable parts or battery replacements.

What limit appears first when both Xeon Gold 5415+ CPUs run at 4.1 GHz turbo continuously?

The dual 1400 W platinum power supplies set the thermal ceiling; sustained turbo on all sixteen cores will hit the power budget before CPU temperature throttles.
