Black 3U rackmount server chassis with blue aluminium front bezel, four 5.25-inch and two 3.5-inch external drive bays

iStarUSA Inc.

iStarUSA Inc. D-300SEA 3U server chassis

SKU CH-WTW7-JYTMH MPN D-300SEA

A 3U rackmount chassis with four 5.25" bays, two external 3.5" bays, one internal 3.5" bay and seven expansion slots

  • Chassis TypeRackmount
  • Form Factor3U
  • ColorBlack
  • Case MaterialAluminum / Steel
  • Motherboard Compatibility12 x 9.6 (ATX, microATX)
  • External 5.25" Drive Bays4

Model D-300SEA

  • 3U rackmount design fits standard 19.00" cabinets
  • 4 external 5.25" bays plus 2 external and 1 internal 3.5" bays
  • 7 expansion slots support full-length add-on cards
  • 2 front USB 2.0 ports with power, reset, and lockable bezel
  • 60mm fan included; optional sensor board adds temperature and fan monitoring

3U Rackmount Chassis with Four 5.25" Bays

The iStarUSA D-300SEA is a 3U rackmount server chassis designed for compact deployments that still require multiple front-accessible drives. It accepts ATX and microATX motherboards up to 12 x 9.6 inches, making it suitable for general-purpose server builds and industrial applications where space is limited.

Single 60mm Fan with Sensor Indicators

Cooling is handled by one 60mm fan, while front-panel LEDs show power, drive activity, temperature and fan status when the optional TC-ISF08 sensor board is installed. The chassis supports 1U or 2U power supplies, allowing builders to match power capacity to their specific component load without prescribing a fixed wattage.

Aluminium and Steel Build with Lockable Bezel

The body combines aluminium and steel, and the front bezel features a key lock to restrict physical access to the drive bays and controls. Seven expansion slots accommodate full-length add-in cards, while two USB 2.0 ports on the front provide convenient peripheral connectivity for maintenance or temporary devices.

Акценти

  • 3U rackmount design fits standard 19.00" cabinets
  • 4 external 5.25" bays plus 2 external and 1 internal 3.5" bays
  • 7 expansion slots support full-length add-on cards
  • 2 front USB 2.0 ports with power, reset, and lockable bezel
  • 60mm fan included; optional sensor board adds temperature and fan monitoring

Спецификации

BrandiStarUSA
SeriesD Storm
ModelD-300SEA
Chassis TypeRackmount
Form Factor3U
ColorBlack
Case MaterialAluminum / Steel
Motherboard Compatibility12 x 9.6 (ATX, microATX)
External 5.25" Drive Bays4
External 3.5" Drive Bays2
Internal 3.5" Drive Bays1
Expansion Slots7
Front Ports2 x USB 2.0
60mm Fans1
FeaturesBlue Bezel
Indicators: Power, HDD, Temperature, Fan (Fan/Temp require sensor board TC-ISF08 )
Switches: Power, Reset
Supported PSU Type: 1U, 2U
Security: Front Bezel Key Lock
Material:
Material of Front Bezel: Aluminum alloy
Material of Handle: SECC Zinc-Coated Steel
Material of Main Chassis: 1.2mm SECC Zinc-Coated Steel ( Japan Made )
Dimensions19.00" x 5.25" x 20.80"
Тегло на пратката12.50 kg
Размери на опаковката679 × 565 × 260 mm

Други версии на този модел

3 още от същата серия

Същото семейство, различна памет, охладител или честота — сравнете, преди да решите.

Въпроси за този артикул

How do I mount the D-300SEA in a 19-inch rack, and which step is often missed?

The chassis is 19.00 inches wide and 3U high; the step often missed is installing the optional sensor board TC-ISF08 so the front temperature and fan indicators actually work.

What will need replacement first on the D-300SEA?

The single 60mm fan is the only moving part; it should be checked regularly and swapped when airflow drops or noise rises.

What thermal limit appears first under sustained load in the D-300SEA?

With only one 60mm fan, the internal air temperature hits its ceiling before the seven expansion slots or four 5.25-inch bays fill up.
