Black flexible flat cable with 22-pin and 15-pin connectors, shielded film both sides

LORDWORLD

LORDWORLD CSI FPC Flexible Cable 22Pin to 15Pin for Raspberry Pi 5 Black

SKU CH-XJ4X-BXDVS

A 22-pin to 15-pin FPC cable with black EMI shielding on both sides connects CSI camera modules to Raspberry Pi 5 or CM4 for stable signal transmission

  • Connects CSI camera modules to Raspberry Pi 5 or CM4 via 22 to 15 pin interface
  • Black EMI shielding film on both sides reduces signal interference for stable transmission
  • Flexible FPC design simplifies routing inside compact enclosures and tight spaces
  • Purpose-built for Raspberry Pi 5 CSI port compatibility with 22-pin to 15-pin conversion
  • 522 mm length provides ample reach for typical camera mounting positions

Raspberry Pi 5 CSI Camera Cable

This 22-pin to 15-pin FPC cable connects a standard CSI camera module to the Raspberry Pi 5 or Compute Module 4. It is built for makers and developers who need a reliable camera link on the newer board. The flexible design allows clean routing inside tight enclosures. Black EMI shielding film on both sides helps maintain signal quality.

Replacing Standard 15-Pin Camera Ribbons

The Raspberry Pi 5 uses a 22-pin CSI connector while most camera modules retain a 15-pin interface. This cable bridges that pin-count difference so existing camera hardware works with the updated platform. The upgrade is worth it when migrating a project from an older Pi to the Pi 5 or CM4 without changing the camera module. Shielded construction reduces interference that can corrupt image data on longer runs.

Check Connector Orientation

Verify that your camera module uses a 15-pin CSI connector and that the target board provides a 22-pin CSI port. Ensure the cable length suits the physical distance between the two connectors in your build. Confirm the pin-one alignment on both ends to avoid reversed insertion. This cable does not adapt non-CSI interfaces or different pin counts.

Акценти

  • Connects CSI camera modules to Raspberry Pi 5 or CM4 via 22 to 15 pin interface
  • Black EMI shielding film on both sides reduces signal interference for stable transmission
  • Flexible FPC design simplifies routing inside compact enclosures and tight spaces
  • Purpose-built for Raspberry Pi 5 CSI port compatibility with 22-pin to 15-pin conversion
  • 522 mm length provides ample reach for typical camera mounting positions

Спецификации

BrandLORDWORLD

Въпроси за този артикул

Will the 22-pin connector fit the Raspberry Pi 5 CSI port?

Yes, the 22-pin end plugs directly into the Raspberry Pi 5 CSI port while the 15-pin end connects to standard CSI camera modules.

How do I insert the cable without damaging the FPC contacts?

Lift the locking flap on each CSI connector, slide the cable in with the exposed contacts facing the board, then press the flap down to lock it.

When should I replace this EMI-shielded FPC cable?

Replace it if the black shielding film tears, the gold contacts show corrosion, or the cable develops permanent kinks that cause intermittent camera errors.
