Silver 21.5 inch fanless all-in-one panel PC with resistive touchscreen and IP65 front protection

partaker

Partaker A17 21.5" IP65 Industrial All-in-One PC Core i5 4th Gen 1.60GHz 8GB DDR3 256GB SSD

SKU CH-BN4W-PY98Q

A fanless 21.5-inch IP65 panel PC with a 5-wire resistive touchscreen, Intel Core i5 4th Gen 1.60GHz, 8GB DDR3 and 256GB SSD for continuous industrial use

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 4th Gen
  • CPU Name1.60GHz
  • GPU/VGA TypeIntel HD Graphics 4400

GPU Intel HD Graphics 4400

Memory 8GB DDR3

  • 4GB DDR3
  • 8GB DDR3

SSD 256GB

HDD None

Precrtane verzije postoje, ali nisu dostupne ovdje.

  • IP65 front panel resists dust and water ingress
  • Fanless aluminium chassis runs silently in noise-sensitive areas
  • 5-wire resistive touch works with gloves or stylus
  • 1920 x 1080 resolution on 21.5" display
  • Intel Core i5 4th Gen with 8GB DDR3 and 256GB SSD

Industrial 21.5" All-in-One with IP65 Front

The Partaker A17 integrates a 21.5 inch TFT LED display, Intel Core i5 4th Gen 1.60GHz processor, 8GB DDR3L memory and a 256GB mSATA SSD into a fanless aluminium chassis rated IP65 on the front panel. It ships with Windows 10 Pro 64-bit installed and is built for continuous 7×24 operation in industrial environments.

Resistive Touch and Legacy Video Limits

The 5-wire resistive touchscreen requires pressure input and delivers 80±5% transmittance at 550 nm, suited for gloved or stylus use but not multi-touch gestures. Video output is restricted to VGA and HDMI ports driven by Intel HD Graphics 4400, so modern DisplayPort or USB-C monitors cannot be connected directly.

Check Mounting Cut-out and DC Power

Verify the 522 x 315 mm panel cut-out matches your enclosure before ordering. The unit runs on 12V DC supplied by an included 100-240V AC adapter; ensure your cabinet provides the correct DC inlet and that operating temperatures stay within 0–50 °C for SSD configurations.

Istaknuto

  • IP65 front panel resists dust and water ingress
  • Fanless aluminium chassis runs silently in noise-sensitive areas
  • 5-wire resistive touch works with gloves or stylus
  • 1920 x 1080 resolution on 21.5" display
  • Intel Core i5 4th Gen with 8GB DDR3 and 256GB SSD

Specifikacije

ModelA17-PA-215TPC-CE5A(I54)-8G256G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 4th Gen
CPU Name1.60GHz
GPU/VGA TypeIntel HD Graphics 4400
Memory Capacity8GB DDR3
SSD256GB
HDDNo
Screen Size21.5"
TouchscreenYes

Druge verzije ovog modela

još 5 u istoj seriji

Ista obitelj, različita memorija, hladnjak ili frekvencija — usporedite prije kupnje.

Pitanja o ovom artiklu

Should I pick the 8GB DDR3 / 256GB SSD model or is there a larger capacity available?

The listed configuration ships with 8GB DDR3L memory and a 256GB mSATA SSD. The board accepts one SODIMM up to 8GB total and also provides a 2.5" SATA bay for an additional drive.

What does the 1.60GHz Core i5 4th Gen actually deliver in daily industrial use?

The quad-core processor runs at 1.60GHz with Intel HD Graphics 4400, providing enough throughput for HMI, SCADA and lightweight edge tasks while the fanless aluminium chassis keeps it silent.

Which video outputs can I use and what resolution do they support?

HDMI and VGA ports are fitted; both can drive the native 1920 x 1080 panel or an external display at up to 1920 x 1080.
