Gray 15 inch industrial all-in-one panel PC with capacitive touchscreen and fanless aluminum chassis

partaker

Partaker A23-I5 6200U-16G512G 15" all-in-one PC

SKU CH-P0VK-MJP6W

15-inch IP65 industrial all-in-one with 10-point capacitive touch, Core i5-6200U, 16 GB DDR4, 512 GB SSD and Windows 11 Pro

  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 6th Gen
  • CPU NameIntel Core i5-6200U
  • GPU/VGA TypeIntel HD Graphics 520

CPU Type Intel Core i5 6th Gen

CPU Name Intel Core i5-6200U

Memory Capacity 16GB DDR4

SSD 512GB

HDD None

Precrtane verzije postoje, ali nisu dostupne ovdje.

  • IP65 front protection for harsh 24/7 environments
  • Fanless aluminium cooling runs silently and resists dust
  • 10-point capacitive touch with 200M touch durability
  • 16GB DDR4 plus 512GB SSD for responsive multitasking
  • HDMI, VGA, dual LAN, dual COM and four USB ports

Industrial panel PC for automation

The Partaker A23 is a 15-inch all-in-one computer built for continuous industrial use. Its IP65-rated front panel resists dust and water jets while the 10-point capacitive touchscreen works with gloves. A fanless aluminum chassis eliminates moving parts for silent 24/7 operation in harsh environments. Windows 11 Pro ships pre-installed for immediate deployment.

Interface limits for integration

The 1024 x 768 resolution and 350 cd/m² brightness suit control-room viewing angles of 80 degrees left, right, top and bottom. Two LAN ports and two COM ports connect legacy PLCs and modern networks simultaneously. HDMI and VGA outputs drive a second display for supervisory screens. Expansion relies on a single mini PCIe slot with a SIM holder for optional 4G or Wi-Fi modules.

Check your mounting and power plan

Verify the 348 x 272 mm cut-out matches your enclosure before ordering. The unit requires a 12 V DC supply from the included 100-240 V AC adapter; no internal PSU is present. Operating temperature tops out at 50 °C with the fitted SSD, so confirm cabinet cooling meets that limit. Storage bays accept one mSATA and one 2.5-inch SATA drive only.

Istaknuto

  • IP65 front protection for harsh 24/7 environments
  • Fanless aluminium cooling runs silently and resists dust
  • 10-point capacitive touch with 200M touch durability
  • 16GB DDR4 plus 512GB SSD for responsive multitasking
  • HDMI, VGA, dual LAN, dual COM and four USB ports

Specifikacije

ModelA23-I5 6200U-16G512G
Form FactorAll-in-One
ColorGray
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 6th Gen
CPU NameIntel Core i5-6200U
GPU/VGA TypeIntel HD Graphics 520
Memory Capacity16GB DDR4
SSD512GB
HDDNo
Screen Size15"
TouchscreenYes

Druge verzije ovog modela

još 5 u istoj seriji

Ista obitelj, različita memorija, hladnjak ili frekvencija — usporedite prije kupnje.

Pitanja o ovom artiklu

Should I pick the 16 GB DDR4 / 512 GB SSD configuration or look for a different memory and storage combination?

This model ships with 16 GB DDR4 and a 512 GB SSD as the only listed configuration; the board accepts up to 16 GB total across two SODIMM slots and offers one mSATA plus one 2.5" SATA bay for additional drives.

What does the Core i5-6200U with HD Graphics 520 actually deliver when the panel is running at 1024×768?

The dual-core 6th Gen i5 and integrated HD 520 handle industrial HMI, light multitasking and video playback smoothly at the native 1024×768 resolution, while the fanless aluminium chassis keeps the system silent during 24/7 operation.

Which I/O standards are built in and what practical limits do they set for expansion?

You get HDMI, VGA, two USB 3.0, two USB 2.0, dual LAN, two COM ports, audio in/out and a 12 V DC jack; a mini-PCIe slot with SIM holder allows adding Wi-Fi or 4G, but storage expansion is limited to mSATA and 2.5" SATA interfaces.
