Brass G1/4 90-degree rotary elbow fitting with 20mm extension, Toxic Candy powder-coated finish

PrimoChill

PrimoChill Male to Female G1/4 90 Degree Rotary 20mm Extension Elbow Fitting Toxic Candy diy cooling

SKU CH-V97C-T2AJN

G1/4 rotary elbow fitting redirects tubing 90 degrees with 20mm extension and 360-degree adjustment

  • TypeFittings

Option Toxic Candy

Prikaži još 9 konfiguracija

Precrtane verzije postoje, ali nisu dostupne ovdje.

  • 360-degree rotary lets you aim the port in any direction
  • 90-degree elbow redirects tubing runs around tight component layouts
  • 20 mm installed base height adds clearance for crowded builds
  • 43 mm total height fits low-profile loops without obstruction
  • Brass construction with SX powder-coated finish resists corrosion in custom loops

Loop Redirection Solution

The PrimoChill Male to Female G1/4 90 Degree Rotary 20mm Extension Elbow Fitting is a DIY cooling component designed for custom liquid loops. It allows builders to change tubing direction quickly at unconventional angles. The rotary function enables the connection to be aimed in any desired direction 90 degrees from the mount. This fits systems needing tight spatial management around components.

G1/4 Thread Compatibility

The fitting uses a standard G1/4 thread for integration into existing water-cooling loops. Brass construction provides durability for continuous coolant contact. The installed base height measures 20mm with a thread depth of 5mm. Total height reaches 43mm when fully seated in the port.

Rotary Clearance And Finish

The 360 degree rotary mechanism allows precise alignment without stressing tubing runs. A 20mm extension creates additional clearance around obstructing hardware. The SX powder coated finish in Toxic Candy resists corrosion and adds visual accent. No active cooling or power draw is involved with this passive fitting.

Istaknuto

  • 360-degree rotary lets you aim the port in any direction
  • 90-degree elbow redirects tubing runs around tight component layouts
  • 20 mm installed base height adds clearance for crowded builds
  • 43 mm total height fits low-profile loops without obstruction
  • Brass construction with SX powder-coated finish resists corrosion in custom loops

Specifikacije

TypeFittings

Druge verzije ovog modela

još 5 u istoj seriji

Ista obitelj, različita memorija, hladnjak ili frekvencija — usporedite prije kupnje.

Pitanja o ovom artiklu

How much extra height does the 20 mm extension add once the fitting is installed in the loop?

The installed base height is 20 mm, so the extension raises the connection point by that amount while keeping total height at 43 mm.

What thread standard does the G1/4 rotary fitting use and what does it limit?

It uses standard G1/4 threads with a 5 mm thread depth, capping compatibility to components that share the same thread pitch and depth.

What clearance is needed to fit the 43 mm tall elbow in a tight build?

You need at least 43 mm of vertical space from the mounting surface, plus room for the 360-degree rotary joint to turn freely.
