Silver rackmount switch with 24 RJ45 ports and two SFP+ uplinks

Ubiquiti Networks

Ubiquiti Networks USW-Pro-Max-24-PoE 24-port Layer 3 PoE++ network switch

SKU CH-V8NN-FXZ1V MPN USW-Pro-Max-24-PoE

A managed 24-port Layer 3 rackmount switch with 16 GbE and eight 2.5 GbE PoE++ ports, two 10G SFP+ uplinks, 400 W PoE budget and 112 Gbps switching capacity

  • FormatRackmount
  • Network Management TypeManaged
  • Primary Ports24 x RJ45 + 2 x SFP+
  • Primary Port SpeedTotal non-blocking throughput 56 Gbps Switching capacity 112
  • Primary Port Type(16) GbE RJ45 ports (8) 1/2.5 GbE RJ45 ports (2) 10G SFP+ po
  • Management InterfaceEthernet In-Band

Model Pro Max 24 PoE

Primary Port 24 Port

  • Layer 3 routing with static routes and DHCP relay for network segmentation
  • 112 Gbps switching capacity and 83.328 Mpps forwarding for high-throughput traffic
  • 400 W total PoE budget across 16 PoE++ and 8 PoE+ ports
  • Etherlighting port LEDs show link speed, location and native VLAN at a glance
  • Two 10 Gbps SFP+ uplinks plus 8 ports at 2.5 GbE for fast downlinks

24-port Layer 3 PoE++ switch for managed networks

The Ubiquiti Networks USW-Pro-Max-24-PoE is a rackmount managed switch with 24 RJ45 ports and two 10G SFP+ uplinks. It provides Layer 3 routing features including static routing, DHCP relay and inter-VLAN routing. The switch suits networks that need high-power PoE++ delivery alongside advanced traffic management.

Thermals noise and power draw in normal use

The unit operates from a universal 100—240V AC supply and includes a USP-RPS DC input for redundant power. Total PoE budget reaches 400W across the 24 downlink ports. Passive cooling handles the thermal load in a standard 1U rack space measuring 44 mm high.

PoE++ port mix decides suitability

Sixteen ports deliver 60W PoE++ using both pair sets while eight ports provide PoE or PoE+ on the standard pairs. Eight of the RJ45 ports support 2.5 GbE speeds with the remaining sixteen at 1 GbE. Buyers needing more than 24 managed ports or a higher aggregate PoE budget should consider larger models.

Erősségek

  • Layer 3 routing with static routes and DHCP relay for network segmentation
  • 112 Gbps switching capacity and 83.328 Mpps forwarding for high-throughput traffic
  • 400 W total PoE budget across 16 PoE++ and 8 PoE+ ports
  • Etherlighting port LEDs show link speed, location and native VLAN at a glance
  • Two 10 Gbps SFP+ uplinks plus 8 ports at 2.5 GbE for fast downlinks

Műszaki adatok

BrandUbiquiti Networks
ModelPro Max 24 PoE
Part NumberUSW-Pro-Max-24-PoE
FormatRackmount
Network Management TypeManaged
Primary Ports24 x RJ45 + 2 x SFP+
Primary Port SpeedTotal non-blocking throughput 56 Gbps
Switching capacity 112 Gbps
Forwarding rate 83.328 Mpps
Primary Port Type(16) GbE RJ45 ports
(8) 1/2.5 GbE RJ45 ports
(2) 10G SFP+ ports
Management InterfaceEthernet In-Band
VLAN SupportYes
Jumbo FramesYes
PoEYes
Layer3
Layer 2 FeaturesIGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs
Layer 3 FeaturesDHCP for locally-managed networks
DHCP relay
Inter-VLAN routing between networks on same switch
Static routing between local networks
Network isolation with ACLs
Port MirroringYes
LEDsSystem Status
RPS Status
ButtonFactory reset
PoE Ports(8) PoE/PoE+ (Pins 1, 2+; 3, 6-)
(16) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
Power(1) Universal input, 100—240V AC, 50/60 Hz
(1) USP-RPS DC input
Max Power Consumption50W (Excluding PoE output)
Dimensions442 x 325 x 44 mm (17.4 x 12.8 x 1.7")
WeightWithout mounting brackets: 5.1 kg (11.3 lb)
With mounting brackets: 5.2 kg (11.5 lb)
CertificationCE, FCC, IC
System RequirementUniFi Network Version 8.0.24 and later
Temperature-5 to 40° C (23 to 104° F)
Humidity10 to 90% noncondensing
Szállítási súly5.53 kg
Csomagméret528 × 432 × 127 mm

A modell további verziói

4 további ebben a termékcsaládban

Ugyanaz a termékcsalád, eltérő memória, hűtés vagy órajel — hasonlítsa össze, mielőtt dönt.

Kérdések a termékről

How do I install the USW-Pro-Max-24-PoE in a rack and which step is often missed?

Mount the 442 x 325 x 44 mm chassis using the included brackets, connect the 100—240V AC supply, then adopt the switch in the UniFi controller before configuring VLANs or PoE profiles — skipping adoption leaves ports in default state.

What maintenance or replacement will the USW-Pro-Max-24-PoE need over time?

The switch has no user-serviceable fans or power modules; plan to replace the entire unit if the 400W PoE budget degrades or if the USP-RPS DC input fails, and keep firmware current via the controller.

Which limit appears first on the USW-Pro-Max-24-PoE under sustained heavy load?

The 400W total PoE budget across 24 ports will cap before the 112 Gbps switching capacity or 56 Gbps non-blocking throughput, especially when multiple 60W PoE++ devices draw power simultaneously.
