Green circuit board with silver aluminium heatsink and M.2 slot

Corn Electronics

Corn Electronics NVMe adapter with heat sink expansion card

SKU CH-4JDJ-TJ82G

Adds an M.2 NVMe SSD to a PCIe x16 slot with an aluminium heat sink for cooling

  • TypePCI Express Controller Card
  • External USB PortsNo
  • Use NVMe SSD without a motherboard M.2 slot
  • PCIe 3.0 x16 delivers up to 32 Gbps bandwidth
  • Aluminium heat sink keeps drive cool under load
  • Supports Key M M.2 sizes 2230 2242 2260 2280
  • Plug-and-play installation with no driver required

Corn Electronics NVMe adapter with heat sink

This Corn Electronics add-on card converts a PCIe x16 slot into a single M.2 Key-M connector for NVMe or AHCI solid-state drives. It accepts 2230, 2242, 2260 and 2280 form factors and operates at PCIe 3.0 x4 bandwidth up to 32 Gbps without requiring any driver installation.

Fits a PCIe x16 slot and frees an M.2 socket

The adapter installs directly into a full-length PCIe x16 slot and is not compatible with x1, x4 or x8 slots. An included aluminium heat sink dissipates heat from the mounted drive, while the plug-and-play design leaves the motherboard M.2 socket available for another device or absent entirely.

Suits builders adding NVMe storage to boards

This card serves users who need to add a Key-M NVMe or AHCI drive to a system lacking a compatible M.2 slot. It does not support SATA-based M.2 Key-B or Key-B/M drives, and it cannot be used in PCIe x1, x4 or x8 slots.

Helstu kostir

  • Use NVMe SSD without a motherboard M.2 slot
  • PCIe 3.0 x16 delivers up to 32 Gbps bandwidth
  • Aluminium heat sink keeps drive cool under load
  • Supports Key M M.2 sizes 2230 2242 2260 2280
  • Plug-and-play installation with no driver required

Tæknilýsing

TypePCI Express Controller Card
External USB PortsNo
Model1 Port

Spurningar um þessa vöru

What is the maximum bandwidth the PCIe 3.0 x16 slot can deliver to the M.2 NVMe SSD?

The card runs at PCIe 3.0 x4 electrical, giving 32 Gbps bandwidth to the NVMe drive.

Does the aluminum heat sink keep the SSD cool during continuous all-day operation?

The included aluminum heat sink provides passive heat dissipation for the M.2 NVMe SSD during sustained workloads.

Must the motherboard have a PCIe x16 slot, or will an x4 or x8 slot work?

The adapter only fits a physical PCIe x16 slot; it will not install in x1, x4 or x8 slots.
