1U rack server in silver chassis with four 3.5 inch drive bays

HP

HP ProLiant DL360 Gen9 4-bay LFF Xeon E5-2670 v3 12-core 2.3GHz 4GB DDR4 2×600GB SAS H240ar

SKU CH-F5KA-5915G

1U rack server with single 12-core Xeon E5-2670 v3, 4GB DDR4, two 600GB 15K SAS drives and H240ar RAID controller

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610
  • 12-core Xeon at 2.3 GHz handles heavy workloads
  • 4 GB DDR4 ECC memory protects data integrity
  • Two 600 GB 15 K SAS drives deliver fast storage
  • Smart HBA H240ar supports RAID 0/1/5/6/10/50/60
  • Dual 500 W hot-swap power supplies keep the server running

ProLiant DL360 Gen9 1U rack server

The HP ProLiant DL360 Gen9 is a 1U rack-mount server built for dense compute workloads. It ships with a single Intel Xeon E5-2670 v3 processor providing 12 cores at 2.3GHz and 4GB of DDR4 ECC registered memory. The chassis supports a second processor and up to 24 DIMM slots for future expansion.

H240ar controller with dual 600GB SAS drives

The integrated Smart HBA H240ar controller delivers 12Gb SAS and 6Gb SATA connectivity with support for RAID 0, 1, 5, 6, 10, 50 and 60. Two 3.5-inch 600GB 15K SAS drives are pre-installed in the four available LFF bays, leaving two bays open for additional capacity. Redundant 500W hot-swap power supplies maintain uptime during a module failure.

Four LFF drive bays limit internal storage

Only four large-form-factor bays are present, so total raw capacity is constrained by 3.5-inch drive sizes. Buyers needing more than four drives or 2.5-inch density must choose a different chassis. No operating system is included, and the Matrox G200 graphics provide only basic console output.

Helstu kostir

  • 12-core Xeon at 2.3 GHz handles heavy workloads
  • 4 GB DDR4 ECC memory protects data integrity
  • Two 600 GB 15 K SAS drives deliver fast storage
  • Smart HBA H240ar supports RAID 0/1/5/6/10/50/60
  • Dual 500 W hot-swap power supplies keep the server running

Tæknilýsing

BrandHP
SeriesProLiant
ModelProliant DL360 G9
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size4GB
Memory TypeDDR4
Max Memory Capacity4GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots24
Storage ControllerHP Smart HBA H240ar Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media DrivesNone
GPU TypeMatrox G200
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports4 x Ports
Expansion SlotsPrimary Riser: 2 PCIe 3.0 Slots (1 & 2) available: 1x Full-Height Half Length, 1x Half-Lenth Half Height. Optional PCIe 3.0 slot 3 - Full-Height Half Height (Secondary PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Aðrar útgáfur af þessari vöru

5 í viðbót í sama vöruflokki

Sama fjölskylda, mismunandi minni, kælingu eða klukkuhraða — berðu saman áður en þú ákveður þig.

Spurningar um þessa vöru

Will the 24 DIMM slots support larger DDR4 modules later?

Yes, the board accepts 4GB, 8GB, 16GB, 32GB and 64GB DDR4 ECC registered modules up to 2400MT/s, limited by the processor capability.

What limits sustained performance first, the CPU thermal envelope or the power supply?

The dual 500W redundant supplies provide headroom; the 12-core 2.3GHz Xeon E5-2670 v3 thermal design power is the first ceiling under continuous load.

How loud are the fans when the server runs 24/7 with both power supplies active?

Fan speed scales with inlet temperature and component load; redundant 500W supplies share load, keeping individual unit stress lower and acoustic output moderate.
