Black tower server chassis with seven 5.25-inch front bays, aluminum front panel, USB 2.0 port, keylock door, and 120mm fan

iStarUSA Inc.

iStarUSA Inc. S-917 server chassis, 7×5.25″ bays, mini-ITX, black

SKU CH-42YV-ET1MK MPN S-917

A compact tower chassis that fits a mini-ITX board and provides seven external 5.25″ bays for high-density storage

  • Chassis TypeTower
  • ColorBlack
  • Case MaterialAluminum / Steel
  • Motherboard CompatibilityMini ITX
  • External 5.25" Drive Bays7
  • Internal 2.5" Drive Bays1

Model S-917

  • Seven external 5.25″ bays for high-capacity storage
  • Mini-ITX motherboard support in a compact tower
  • Lockable front door secures installed drives
  • One 120 mm fan provides active cooling
  • Aluminium front bezel with USB 2.0 port

Compact storage tower for mini-ITX builds

The iStarUSA S-917 is a tower chassis that accepts a mini-ITX motherboard and provides seven external 5.25-inch bays plus one internal 2.5-inch bay. It targets users who need dense removable-media or hot-swap capacity in a footprint of 7.23 by 12.68 by 18.82 inches.

Straightforward assembly

The case uses standard ATX PS2 power supply mounting and two expansion slots, so most mini-ITX boards and PSUs drop in without adapters. The front door keylock and aluminum bezel add physical security but require the door to be unlatched before any drive cage can slide out.

Steady airflow under continuous operation

A single 120 mm fan draws air through the front panel across the drive bays and exhausts at the rear, keeping temperatures stable during long backup or archiving sessions. The SECC 0.8 mm chassis resists vibration when all seven bays are populated, preventing resonance that can appear in lighter enclosures.

Helstu kostir

  • Seven external 5.25″ bays for high-capacity storage
  • Mini-ITX motherboard support in a compact tower
  • Lockable front door secures installed drives
  • One 120 mm fan provides active cooling
  • Aluminium front bezel with USB 2.0 port

Tæknilýsing

BrandiStarUSA
ModelS-917
Chassis TypeTower
ColorBlack
Case MaterialAluminum / Steel
Motherboard CompatibilityMini ITX
External 5.25" Drive Bays7
Internal 2.5" Drive Bays1
Expansion Slots2
Front PortsUSB 2.0
120mm Fans1
FeaturesSleek Front Panel with Power On & Reset Button
7x5.25" Bays Available for Mobile Drive Cage
Aluminum Front Panel with USB2.0
Front Door keylock design to secure data inside
Heavy Duty SECC Construction
Compatible with Mini Redundant Power Supply
Support Standard I/O Slot
Support mini-ITX Motherboard
Power and HDD LED Indicator
One 120mm Cooling Fan
Internal 2.5" Bay for OS HDD
Dimensions7.23" x 12.68" x 18.82"
Sendingarþyngd2.27 kg
Stærð sendingar610 × 457 × 254 mm

Aðrar útgáfur af þessari vöru

1 í viðbót í sama vöruflokki

Sama fjölskylda, mismunandi minni, kælingu eða klukkuhraða — berðu saman áður en þú ákveður þig.

Spurningar um þessa vöru

How can I confirm the S-917 is running correctly after assembly?

The front panel power and HDD LEDs will illuminate when the system is on and the OS drive is active, and the single 120 mm fan should spin quietly.

What comes with the S-917 and what must I purchase separately?

The chassis includes the aluminum front bezel with one USB 2.0 port, a front door with keylock, one 120 mm fan, seven 5.25″ bays for mobile cages, one internal 2.5″ bay, and two expansion slots; you must supply a mini-ITX motherboard, an ATX PS2 power supply, drives, and any mobile drive cages.

Which S-917 configuration should I choose for maximum drive capacity?

All S-917 units are identical — seven 5.25″ external bays and one internal 2.5″ bay — so capacity depends on the mobile cages and drives you install, up to the 42-bay potential mentioned for the series.
