Silver 12.1 inch industrial all-in-one panel PC with resistive touchscreen

partaker

partaker A2-PA-121TPC-CE5B(I56) 12.1" all-in-one PC Core i5 6th Gen 2.0GHz 8GB DDR3 128GB SSD

SKU CH-T4PS-BT8G5

A 12.1 inch industrial all-in-one with IP65 front protection, Intel Core i5 6th Gen 2.0GHz, 8GB DDR3, 128GB SSD and a high-temperature 5-wire resistive touchscreen

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 6th Gen
  • CPU Name2.00GHz
  • GPU/VGA TypeIntel Iris Graphics 540

GPU Intel Iris Graphics 540

Memory 8GB DDR3

SSD

HDD None

  • None
  • 1TB

Yfirstrikaðar útgáfur eru til, en ekki til hér.

  • IP65 front protection seals out dust and water jets
  • Fanless aluminium chassis runs silently in noise-sensitive areas
  • Five-wire resistive touch works with gloves or stylus
  • 1 inch 1024 x 768 display fits tight machine panels
  • Core i5 6th Gen with 8 GB DDR3 and 128 GB SSD handles industrial workloads

12.1" Industrial Panel PC

The Partaker A2-PA-121TPC-CE5B(I56) is a compact all-in-one computer built for embedded industrial use. It integrates a 12.1" TFT LED display with an IP65-rated front panel into a fanless aluminium chassis. A 6th Gen Intel Core i5 processor at 2.00GHz and Intel Iris Graphics 540 drive the system. Windows 10 Pro comes pre-installed for immediate deployment.

8GB DDR3L Memory and Dual Storage Bays

The single SODIMM slot runs DDR3L at 1333 or 1600 MT/s and is populated with 8GB, reaching the maximum supported capacity. Storage uses one mSATA SSD and one 2.5" SATA bay; the unit ships with a 128GB SSD installed. The resistive touchscreen is rated for 200 million touches and operates in high-temperature environments. Memory headroom is fixed at 8GB, so workloads requiring more RAM cannot be accommodated.

VGA, HDMI and Legacy I/O Interfaces

Video output is provided through VGA and HDMI ports driving the internal 1024 x 768 panel or an external display. Connectivity includes two USB 3.0 ports, two USB 2.0 ports, one LAN port, two COM ports and audio in/out. A full-size Mini PCIe slot with a SIM socket allows wireless expansion. The DC 12V input accepts 100-240V AC via the included adapter. The resistive touch technology does not support multi-touch gestures common on capacitive screens.

Helstu kostir

  • IP65 front protection seals out dust and water jets
  • Fanless aluminium chassis runs silently in noise-sensitive areas
  • Five-wire resistive touch works with gloves or stylus
  • 1 inch 1024 x 768 display fits tight machine panels
  • Core i5 6th Gen with 8 GB DDR3 and 128 GB SSD handles industrial workloads

Tæknilýsing

ModelA2-PA-121TPC-CE5B(I56)-8G128G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 6th Gen
CPU Name2.00GHz
GPU/VGA TypeIntel Iris Graphics 540
Memory Capacity8GB DDR3
HDDNo
Screen Size12.1"
TouchscreenYes

Aðrar útgáfur af þessari vöru

5 í viðbót í sama vöruflokki

Sama fjölskylda, mismunandi minni, kælingu eða klukkuhraða — berðu saman áður en þú ákveður þig.

Spurningar um þessa vöru

Will the 12.1" panel PC's VGA and HDMI ports drive my older 1024 x 768 monitor alongside the built-in screen?

Yes, the unit provides both VGA and HDMI outputs that can drive an external display at 1024 x 768 while the internal panel runs at its native resolution.

How can I verify the Intel Iris Graphics 540 and 8GB DDR3L memory are active after first boot?

Open Device Manager in Windows 10 Pro — the display adapter will show Intel Iris Graphics 540 and the installed memory will report 8GB DDR3L 1333/1600.

Which items ship in the box and what must I source separately for a typical embedded install?

The package includes the panel PC, 12V power supply, power cord, embedded buckle kits and warranty card; any Mini PCIe Wi-Fi/4G module, SIM card or additional 2.5" SATA drive are not included.
