21.5 inch flat front panel all-in-one PC with resistive touchscreen and fanless aluminium alloy chassis

partaker

Partaker A22 all-in-one PC i7-10510U 32GB 512GB 21.5" resistive IP65

SKU CH-7G33-K0Q7D

Industrial 21.5" all-in-one with IP65 front panel, resistive touch, Core i7-10510U, 32GB DDR4, 512GB SATA SSD, Windows 11 Pro, fanless aluminium chassis, 9-36V DC input, dual LAN, dual COM, HDMI.

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 10th Gen
  • GPU/VGA TypeIntel UHD Graphics
  • Memory Capacity32GB DDR4
  • Maximum Memory Supported32 GB

CPU Type Intel Core i7 10th Gen

Memory Capacity 32GB DDR4

SSD 512GB

  • IP65 front panel resists dust and water jets
  • Resistive touchscreen works with gloves or stylus
  • Fanless aluminium chassis runs silently 24/7
  • Wide 9-36 V DC input suits industrial power
  • Dual Intel LAN plus four USB 3.0 ports

Industrial all-in-one with IP65 front panel

The Partaker A22 integrates a 21.5 inch TFT LED display with a resistive touchscreen into a sealed aluminium chassis rated IP65 on the front. An Intel Core i7-10510U processor, 32 GB of DDR4 memory and a 512 GB SATA SSD come pre-loaded with Windows 11 Pro for immediate deployment in factory or kiosk environments.

Fanless thermal design for continuous operation

Passive cooling through the alloy body eliminates moving parts, allowing the system to run 24/7 across a 0 to 50 °C commercial range or -20 to 60 °C with an industrial SSD. The CPU sustains its workload without throttling from dust-clogged fans, while the resistive screen tolerates gloved or stylus input in harsh conditions.

Wide-voltage DC input and legacy I/O

A 9 to 36 V Phoenix connector accepts unstable plant power without an external adapter, and dual Intel gigabit LAN ports provide redundant wired networking. Two configurable COM ports support RS232, RS422 or RS485 for PLCs and older sensors, while a single Mini PCIe slot with a SIM holder adds optional wireless connectivity.

Helstu kostir

  • IP65 front panel resists dust and water jets
  • Resistive touchscreen works with gloves or stylus
  • Fanless aluminium chassis runs silently 24/7
  • Wide 9-36 V DC input suits industrial power
  • Dual Intel LAN plus four USB 3.0 ports

Tæknilýsing

ModelA22-New-I7-10810U-32G512G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 10th Gen
GPU/VGA TypeIntel UHD Graphics
Memory Capacity32GB DDR4
Maximum Memory Supported32 GB
SSD512GB
HDDNo
Screen Size21.5"
TouchscreenYes

Aðrar útgáfur af þessari vöru

5 í viðbót í sama vöruflokki

Sama fjölskylda, mismunandi minni, kælingu eða klukkuhraða — berðu saman áður en þú ákveður þig.

Spurningar um þessa vöru

Does the fanless aluminium chassis keep the Core i7-10510U quiet and cool during continuous 24/7 operation?

Yes, the aluminium alloy fanless design provides silent, energy-efficient cooling rated for 7×24 hr stability in 0–50 °C commercial or –20–60 °C industrial environments.

Which cables and peripherals must I already have to power and connect this unit?

You need a DC source of 9–36 V via the 2‑pin Phoenix connector (a 12 V 5 A adapter is included), plus Ethernet cables for the two LAN ports, HDMI cable for display output, USB devices, and serial cables if using the two COM ports.

Can the two Intel Gigabit LAN ports and the two COM ports work with my existing PLCs and HMIs?

The dual Intel 1000 M LAN ports handle standard Ethernet, while the two COM ports are configurable for RS‑232, RS‑422 or RS‑485 to link directly with legacy industrial equipment.
